Uplift Desk V2 F500 C-Frame Manual page 16

Insert Grommet Covers (optional)
Follow the steps below for installing Grommet Covers,
if a different grommet option was selected, follow the
instructions included with your grommet option.
A. Place the Grommet Covers over the grommet holes and
press down until the edges of the Grommet Covers are
flush with the desktop surface.
B. Remove the Grommet Cover lid or rotate the
aperture cover to pass cables through the
Grommet Cover housing.
C. Replace the lid.
Position Desk
Position the desk where you would like it to be. Don't lift the
desk by just the desktop, doing so may put undue stress on
the attachment screws and threaded inserts. Hold the frame
Side Brackets when lifting.
A. If your desk has Casters, moving is easy. If the Casters
include locks, unlock them then roll the desk to the
desired location. Once in place, relock the Casters to keep
the desk stationary and improve stability.
B. If your desk does not have Casters, it's recommended to
use two people to lift the desk on each side-do not drag it.
Be sure to lift by placing your hands under the frame Side
Brackets where indicated by the arrows instead of lifting
by the desktop.
Prepare Desk & Surroundings
A. Check the desk's surroundings to make sure there will
be no obstacles within the desk's path while it is being
raised or lowered. Do not place any objects underneath
the desk that are taller than 21" and be aware of any
accessories mounted above or below your desk.
B. Adjust the Leveling Glides as needed to level the desk.
Each Leveling Glide provides up to ⅜" of leveling.
C. Ensure that the Power Cord and all accessory cords are
long enough to accommodate the raising and lowering
of your desk.
D. Plug your desk into a grounded, 100-240V power outlet.
If you have a Keypad with a display you should see it
light up confirming the desk is powered. If you have
a Keypad without a display, look at the Control Box
under the desk to see if the small LED indicator is
illuminated.
E. Perform the desk reset procedure below. Slowly lower
and raise the desk while watching all cables and
clearances to ensure there are no cable snags or
obstacles.
16
Grommet Cover lid removed
Lift by placing hands here on frame Side Brackets.
Power Indicator LED
Grommet Cover aperture opened
