Keypad Lock - Uplift Desk V2 F500 C-Frame Manual

Perform Desk Reset Procedure
IMPORTANT: Before using your desk, perform the Desk Reset Procedure below to sync the Legs and Control Box.
1. Remove all items from under the desk to allow it to travel to its lowest height.
2. Press the down button once.
3. Hold the down button until the desk stops at its lowest position.
4. Hold the down button again for 30 seconds or until the display changes. Keypads with a display will show "ASr" when
ready to reset. Paddle Keypads will display "RESET."
5. Hold the down button again until the desk lowers slightly, rises, and stops. If the desk didn't move, try this step again.
6. Try operating the desk. If the desk is working properly, you're done. If the desk is not working properly, continue with the
following steps.
7. Unplug the power cord from the electrical outlet.
8. Hold the down button for 10 seconds to discharge any stored power in the control box.
9. Plug the desk back in and restart the Desk Reset process steps a second time.
10. Try operating the desk again. If the desk is working properly, you're done and the desk is ready to use.
If you have an Advanced Keypad, see the Programming section below for further information on how to use your Keypad.
These UPLIFT Desk programming instructions are compatible with all UPLIFT Advanced Keypads except the Advanced
Paddle Keypad.
For Advanced Paddle Keypad programming steps, refer to the instructions provided with that Keypad.
Set & Use Memorized Heights
Save heights on the keypad:
1. Hold the up or down button to move the desk to the
desired height.
2. Tap the "M" button followed by a number button (1, 2, 3,
or 4) to assign the current height to that number.
3. Once the memory buttons are programmed, tap a
numbered button and the desk will automatically
move to the preset height.
If you would rather the button be pressed and held
instead of tapped to make height adjustments, see One-
Touch or Constant-Touch below.
Programming (Advanced Keypads only)
© UPLIFT Desk • 800-349-3839 • info@upliftdesk.com •

Keypad Lock

Lock the keypad to prevent accidental adjustments:
1. Hold the "M" button until the display shows "LOC."
2. To unlock your keypad, hold the "M" button until the
display shows the current numeric height setting.
In the event of a power outage, the keypad will return to
the unlocked setting.
upliftdesk.com 17
