Uplift Desk V2 4-Leg Assembly Instructions

V2 4-Leg Standing Desk
Foot Replacement Instructions
FRM582
Package Contents
Recommended Assembly Workspace & Practices
• Place all parts on a clean surface such as a rug or carpet to avoid scratches.
• Two or more people are recommended for assembly.
• Remove all packaging materials before beginning the assembly process.
© UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com
V2 4-Leg Foot
(qty 2)
M6x12 Machine Screws
(qty 16)
Step 1
A. Remove all objects, accessories, and attached
components from desk since you will be inverting
it for this installation.
B. Press and hold the Down Button to bring the desk
to its lowest position, then unplug the desk from
the electrical outlet.
C. Prior to flipping the desk over, move it to a suitable
area free from clutter or obstruction. We recom-
mend resting the desktop on a carpet or blanket.
Be aware of any cables or attached components
and secure them before flipping the desk.
• Note: When flipping the desk, always hold the
frame and the desktop together. Lifting by the
desktop only could put stress on improperly
fastened screws connecting the desktop to the
frame and may cause them to separate from the
frame if they were not attached properly.
D. You and a friend should each hold on to the rear
edge of the desktop with one hand and hold a leg
with the other hand.
E. Supporting both the desk frame and the desktop,
slowly tilt the desktop toward the rear of the desk
until the back edge of the desktop is resting on the
ground.
F. Hold onto the leg and the front edge of the desk-
top, then tilt the desk another 90 degrees until the
desk is upside down and resting on a carpet or
blanket.
4mm Allen Wrench
1
