SCM186 NXP i.MX 8M Plus ARM-based Evaluation Kit

1.1 Features

⚫ SMARC 2.0 (82 x 50 mm)
⚫ NXP i.MX 8M Plus 1.8GHz SoC with Quad A53
⚫ Neural Processing Unit (NPU), up to 2.3 TOPS
⚫
Cortex-M7 for Real-time Control
⚫ Dual CANbus
⚫ HDMI up to 4K Resolution
⚫
Dual-channel 24-bit LVDS
⚫ 10/100/1000 Mbps Ethernet
⚫ USB 3.2 Gen1
⚫
MIPI-CSI
⚫ Audio
⚫ Yocto 3.3

1.2 Specifications

⚫ CPU
◼ NXP i.MX 8M Plus 1.8GHz SoC with Quad A53
⚫ System Memory
◼ LPDDR4 4GB (option, up to 6GB)
⚫ AI Accelerator
◼ NPU, up to 2.3 TOPS
⚫ Operating System
◼ Yocto V3.3, Linux Kernel 5.10.35
⚫ Storage
◼ SDIO3.0 interface
◼ eMMC NAND flash chip on module; default is 8GB (option, up to 32GB)
⚫
Graphics
◼ Dual-channel 24-bit LVDS
◼ HDMI with up to 1920 x 1080 resolution at 60Hz and 3840 x 2160 resolution at
30Hz
⚫ Ethernet
◼ One supports 10/100/1000 Mbps data transfer rates
⚫
USB Interface
◼ Dual USB 3.2 Gen1
◼ Quad USB 2.0
