AXIOMTEK SCM186 User Manual page 19

P-Pin Primary (Top) Side
P137 SER2_RX
P138 SER2_RTS#_INPUT
P139 SER2_CTS#_OUTPUT
P140 SER3_TX
P141 SER3_RX
P142 GND
P143 CAN0_TX
P144 CAN0_RX
P145 CAN1_TX
P146 CAN1_RX
P147 +5V
P148 +5V
P149 +5V
P150 +5V
P151 +5V
P152 +5V
P153 +5V
P154 +5V
P155 +5V
P156 +5V
13
SCM186 NXP i.MX 8M Plus ARM-based Evaluation Kit
S-Pin Secondary (Bottom) Side
S137 LVDS0_3+
S138 LVDS0_3-
S139 I2C2_SCL
S140 I2C2_SDA
S141 LCD0_BKLT_PWM
S142 NC
S143 GND
S144 NC
S145 WATCH_DOG
S146 PCIE_WAKE#
S147 VDD_RTC
S148 LID
S149 SLEEP
S150 VIN_PWR_BAD#
S151 CHARGING
S152 CHARGER_PRSNT
S153 CARRIER_STBY
S154 CARRIER_PWR_ON
S155 FORCE_RECOV
S156 BATLOW#
S157 TEST#
S158 GND
SCM186 Board and Pin Assignments
