3.4

Boot the Board

This section explains the step and notices for boot-up Herodotus platform.

3.4.1 Preparation

Please check the following items before booting the system, some procedures may require to
be operated without the case.
Boot from EMMC
To make sure the switch on SCM186 SoM is set 0b'1010' as below figure.
⚫
Boot from Micro SD
To make sure the switch on SCM186 SoM is set 0b'1011' as below figure.
⚫
⚫
Micro SD card is installed in the slot, and the Micro SD card is programmed with the
procedure of CH.2.
⚫ For the platform boot procedure, these accessories are required.
◼ HDMI cable
◼ USB keyboard and mouse
◼ (Optional)Console cable and USB to RS232 bridge cable
◼ (Optional)Ethernet
20
Set switch as 1010,
boot by eMMC
Set switch as 1011,
boot by SD
