AXIOMTEK SCM186 User Manual page 18

SCM186 NXP i.MX 8M Plus ARM-based Evaluation Kit
P-Pin Primary (Top) Side
P90 PCIE_A_TX-
P91 GND
P92 HDMI_D2+
P93 HDMI_D2-
P94 GND
P95 HDMI_D1+
P96 HDMI_D1-
P97 GND
P98 HDMI_D0+
P99 HDMI_D0-
P100 GND
P101 HDMI_CK+
P102 HDMI_CK-
P103 GND
P104 HDMI_HPD
P105 HDMI_DDC_CK
P106 HDMI_DDC_DAT
P107 HDMI_CEC
P108 GPIO0
P109 GPIO1
P110 GPIO2
P111 GPIO3
P112 GPIO4
P113 GPIO5
P114 GPIO6
P115 GPIO7
P116 GPIO8
P117 GPIO9
P118 GPIO10
P119 GPIO11
P120 GND
P121 I2C_PM_CK
P122 I2C_PM_DAT
P123 BOOT_SEL0#
P124 BOOT_SEL1#
P125 BOOT_SEL2#
P126 Power On reset
P127 RESET_IN#
P128 POWER_BTN#
P129 SER0_TX
P130 SER0_RX
P131 SER0_RTS#_INPUT
P132 SER0_CTS#_OUTPUT
P133 GND
P134 SER1_TX
P135 SER1_RX
P136 SER2_TX
12
S-Pin Secondary (Bottom) Side
S90 NC
S91 NC
S92 GND
S93 NC
S94 NC
S95 NC
S96 NC
S97 NC
S98 NC
S99 NC
S100 NC
S101 GND
S102 NC
S103 NC
S104 NC
S105 NC
S106 NC
S107 NC
S108 LVDS1_CK+
S109 LVDS1_CK-
S110 GND
S111 LVDS1_0+
S112 LVDS1_0-
S113 NC
S114 LVDS1_1+
S115 LVDS1_1-
S116 NC
S117 LVDS1_2+
S118 LVDS1_2-
S119 GND
S120 LVDS1_3+
S121 LVDS1_3-
S122 NC
S123 NC
S124 GND
S125 LVDS0_0+
S126 LVDS0_0-
S127 LCD0_BKLT_EN
S128 LVDS0_1+
S129 LVDS0_1-
S130 GND
S131 LVDS0_2+
S132 LVDS0_2-
S133 LCD0_VDD_EN
S134 LVDS0_CK+
S135 LVDS0_CK-
S136 GND
Board and Pin Assignments
