SCM186 NXP i.MX 8M Plus ARM-based Evaluation Kit

2.6 SMARC Module Top/Bottom Side Pinout Table

P-Pin Primary (Top) Side
P1 SMB_ALERT#
P2 GND
P3 CSI1_CK+
P4 CSI1_CK-
P5 NC
P6 NC
P7 CSI1_DP0
P8 CSI1_DN0
P9 GND
P10 CSI1_DP1
P11 CSI1_DN1
P12 GND
P13 CSI1_DP2
P14 CSI1_DN2
P15 GND
P16 CSI1_DP3
P17 CSI1_DN3
P18 GND
P19 GBE0_MDI3-
P20 GBE0_MDI3+
P21 GBE0_LINK100#
P22 GBE0_LINK1000#
P23 GBE0_MDI2-
P24 GBE0_MDI2+
P25 GBE0_LINK_ACT#
P26 GBE0_MDI1-
P27 GBE0_MDI1+
P28 NC
P29 GBE0_MDI0-
P30 GBE0_MDI0+
P31 NC
P32 GND
P33 SDIO_WP
P34 SDIO_CMD
P35 SDIO_CD#
P36 SDIO_CK
P37 SDIO_PWR_EN
P38 GND
P39 SDIO_D0
P40 SDIO_D1
10
S-Pin Secondary (Bottom) Side
S1 I2C2_SCL
S2 I2C2_SDA
S3 GND
S4 NC
S5 I2C3_SCL
S6 NC
S7 I2C3_SDA
S8 CSI0_CK+
S9 CSI0_CK-
S10 GND
S11 CSI0_DP0
S12 CSI0_DN0
S13 GND
S14 CSI0_DP1
S15 CSI0_DN1
S16 GND
S17 NC
S18 NC
S19 NC
S20 NC
S21 NC
S22 NC
S23 NC
S24 NC
S25 GND
S26 NC
S27 NC
S28 NC
S29 NC
S30 NC
S31 NC
S32 NC
S33 NC
S34 GND
S35 USB_DP_DN1
S36 USB_DM_DN1
S37 NC
S38 AUDIO_MCK
S39 AUDIO _TXFS
S40 AUDIO _TXD
Board and Pin Assignments
