Chapter 1 Introduction; Features - AXIOMTEK CEM510 User Manual

The CEM510 is a COM Express
th
7 generation Intel
QM175/HM175/CM238 chipset which supports the most updated high speed I/Os like
PCI-Express Gen 3 at 8GT/s, SuperSpeed USB 3.0 at 5Gb/s, and SATA-600 at 6Gb/s. The
CEM510 fully complies with COM Express
PCI-Express, Gigabit Ethernet, HD audio interface, LVDS LCD and 3 configurable DDI for
more flexible digital display options.
1.1

Features

th

7 generation Intel
®
 Intel PCH QM175/HM175/CM238
 Two 260-pin DDR4 SO-DIMM sockets supporting up to 32GB memory capacity (CM238
supports ECC memory).
 24 Lanes of PCI-Express support Gen 3 at 8GT/s
 4 SATA-600
 4 USB 3.0 ports

8 USB 2.0 ports
 TPM v1.2
Introduction
CEM510 COM Express
TM
Type 6 Basic Module powered by BGA type quad/dual core
® TM
Core i7/ i5/
®
Core™ i7/ i5/ i3 processors
