INCEPTION HALSTON DECORATIVE FRONT
IMPORTANT! This appliance requires an installed decorative front to act as a barrier preventing direct contact
with the heater. DO NOT operate the appliance with the front removed.
Decorative front must be ordered at time of appliance purchase. If decorative front is not present, contact
dealer.
Y
I
Inside Fit
Finishing
in.
SF-HAL-36
mm
* Refer to Section 4.D for detailed clearances to overlapped finishing materials.
Figure 3.3 Decorative Front Dimensions - Halston
Mesh: Integral to
Decorative Barrier Front
(Overlap Finishing)
(Inside Fit Finishing)
A
B
C
32-7/16
21-1/4
37-3/16
824
540
945
SimpliFire • SF-INC36 Owner's - Installation Manual • 4200-900 Rev D • 8/23
A
C
G*
X
D
E
F
1-1/8
6-1/4
34
36-1/8
29
159
864
H*
B
Overlap
Finishing
E
D
0 IN. to 1 IN.
Overlap Fit
Finishing
See Section
4.D.
G
H
I
32-5/8
32-7/8
37-3/8
918
829
835
949
F
1 IN. to 6 IN.
Inside Fit
Finishing
X
Y
34-3/8
873
9
