SimpliFire SF-BI30-E Owner's Manual

Hide thumbs Also See for SF-BI30-E:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
Model(s):
SF-BI30-E
SF-BI36-E
• Important operating
a n d m a i n t e n a n c e
instructions included.
Congratulations!
Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fireplaces.
The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions
before using appliance.
INSTALLER: DO NOT DISCARD THIS MANUAL -
LEAVE FOR HOMEOWNER - SAVE THESE INSTRUCTIONS
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-BI30-E and is the answer not in the manual?

Questions and answers

Related Manuals for SimpliFire SF-BI30-E

Summary of Contents for SimpliFire SF-BI30-E

  • Page 1 WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions before using appliance. INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER - SAVE THESE INSTRUCTIONS SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 2: Important Instructions

    14 AWG minimum size and rated to not less than 1875 or after the appliance malfunctions, has been dropped or watts. damaged in any manner. Return appliance to authorized service facility for examination, electrical or mechanical adjustment or repair. • Do not use outdoors. SAVE THESE INSTRUCTIONS SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 3: Table Of Contents

    F. Contact Information ......16 SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 4: Warranty

    Fire fireplace within one year following the date of original purchase, that the SimpliFire fireplace will be free from defects in materials and workmanship at the time of manufacture. If a SimpliFire fireplace is found to be defective in materials or workmanship during the applicable warranty period, HHT will, at its option, repair or replace the SimpliFire fireplace.

  • Page 5: General Information

    • Reorient or relocate the receiving antenna • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Homeowner Reference Information We recommend that you record the following pertinent information about your fireplace. Model Name: ___________________________________________ Date purchased/installed: _ _________________ Serial Number: _ _________________________________________ Location on fireplace: _____________________ Dealership purchased from: _______________________________ Dealer Phone: __________________________ Notes: _______________________________________________________________________________________ _____________________________________________________________________________________________ SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 6: Getting Started

    2-3/8 in. 3-1/2 in. units: inches SHELL SIZE TRIM SIZE FLAME VIEW OTHER SIZE MODEL 31-1/8 SF-BI30-E 26-3/4 11-13/16 28-11/32 21-13/32 31-1/8 29-15/16 SF-BI30-E 31-1/4 11-13/16 35-13/16 30-3/8 34-1/4 25-7/8 29-7/8 SF-BI36-E SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 7: Location

    3 ft. (0.9 m) from the front of the electric fireplace. 12 in. 2 in. 6 in. 2 in. 2 in. Measurements from top surface of the door front. Figure 3.1 Minimum Vertical and Maximum Horizontal Dimensions of Combustible Mantels. SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 8: Installation

    NOTICE: Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams are not drawn to scale. Actual installation may vary due to individual design preference. 1/2 in. 1/2 in. MODEL 27-1/2 47-5/8 33-1/2 23-5/8 SF-BI30-E 37-3/8 35-1/2 37-3/4 26-1/2 SF-BI36-E Figure 4.1 Clearance Requirements SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 9: Appliance Preparation

    B. Appliance Preparation Install mounting brackets (4) by aligning them with the pre- drilled holes located on the side of the appliance . Use two screws (ST4 x 8) per bracket to secure to the appliance. See Figure 4.2 and 4.3. PRE-DRILLED HOLES Figure 4.2 Pre-drilled Hole Location BRACKET LOCATION BRACKET LOCATION Figure 4.3 Bracket Locations SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 10: Installation Into Existing Fireplace

    F. Electrical Connection to finish up to the fireplace glass frame. Ensure that you Note: All wiring must be completed prior to finish- leave adequate room to remove and replace the glass ing the unit. frame. See Figure 4.4. 36 1/4 in. 30 1/4 in. SF-BI30-E Finishing Dimension SF-BI36-E Finishing Dimension Figure 4.4 Finishing Dimensions SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 11: Operating Instructions

    - Press again turns 1500W power on. Appliance will beep and illuminate 2 red LEDs. Note: A harmless slight brief odor may occur during first - Press third time turns heater off. use or after prolonged period of storage. NOTE: A. Manual Switch Function There is a brief delay between the heater command and The appliance can be operated by both remote control the heating turning ON. When the appliance receives and manual button. Once the unit has been properly a heater ON command, the appliance blower will turn connected to a grounded electrical circuit, the unit can ON for 8 seconds before the heater turns ON. There is be turned ON by pressing the Flame button. In any ac- also an 8 second delay between heater off and blower tive Flame mode, the Heater button function is available. shutdown. If the Flame effect is OFF, there is no Heater button function. See Figure 5.1. Flame Button By pressing the FLAME button, the unit will cycle through four flame effects. Flame Button Heater Button Figure 5.1 Manual Operating Switches SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 12: Operating By Remote Control

    THERMOSTAT Temperature adjusts from 16 °C but cannot be - 28 °C (61 °F - 82 °F). Power adjusted. button must be on to set from °C to °F. Hold for 3 seconds and the LCD display from °C to °F. Pressing the Timer button sets Remote will display Fireplace emits single audible beep the time desired for the fireplace the time setting to confirm command to transition to run. The Timer can be set from selected. If in Stand- between four FLAME states. TIMER .5 hour up to 9 hours in 1 hour by mode time will increments. display but cannot be adjusted. Fireplace will emit one audible Pressing the spotlight button will LIGHT No indicator. beep as it transitions between switch the spotlight on and off. spotlight on and off states. SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 13: Maintenance

    Red 16AWG 16AWG AC120 60Hz Blue 16AWG Yellow/Green Blue 16AWG Wiring 16AWG 16AWG Blue Terminal White 17AWG Blue 16AWG Wiring Terminal Black 20AWG Blue 16AWG Blue 16AWG Figure 6.1 Electrical Wiring Diagram Yellow 17AWG SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 14: Service Parts List

    Depot ITEM DESCRIPTION COMMENTS PART NUMBER Heater Assembly includes Control Board and Fan HEATER-BI30 Rotisserie Motor, Rod & 3 screws ROTISSERIE-BI30 LED-BI30 LED Strips, 3 Strips Log/Grate Assembly LOGS-BI30 Refractory Kit REFRACTORY-BI30 FLAME-BI30 Flame Screen Front FRONT-BI30 Glass GLA-BI30 REMOTE-SF-ELEC Remote Hardware Bag HRDW-BI Includes: Mounting Brackets, Screw (ST4 x 8), Screws (ST4 x 12) Installation Manual 2040-900 1/15 SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 15: Service Parts

    Depot ITEM DESCRIPTION COMMENTS PART NUMBER HEATER-BI36 Heater Assembly includes Control Board and Fan Rotisserie Motor, Rod & 3 Screws ROTISSERIE-BI36 LED Strips, 3 Strips LED-BI36 Log/Grate Assembly LOGS-BI36 Refractory Kit REFRACTORY-BI36 Flame Screen FLAME-BI36 FRONT-BI36 Front Glass GLA-BI36 Remote REMOTE-SF-ELEC Hardware Bag HRDW-BI Includes: Mounting Brackets, Screw (ST4 x 8), Screws (ST4 x 12) Installation Manual 2040-900 1/15 SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

  • Page 16: Contact Information

    • Read, understand and follow • Important operating • Leave this manual with a n d m a i n t e n a n c e these instructions for safe party responsible for use installation and operation. instructions included. and operation. Printed in China - Copyright 2015 SimpliFire • SF-BI30-E, SF-BI36-E • 2040-900 Rev. G • 1/15...

This manual is also suitable for:

Sf-bi36-e
