Congratulations!
Congratulations on selecting a SimpliFire Electric Appliance, an elegant and clean alternative to wood and gas burning
appliances. The SimpliFire electric appliance you have selected is designed to provide the utmost in safety, reliability, and
efficiency.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions
before using appliance.
INSTALLER: DO NOT DISCARD THIS MANUAL -
LEAVE FOR HOMEOWNER - SAVE THESE INSTRUCTIONS
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
SimpliFire • SF-INS25, SF-INS30, SF-INS35 • 2042-970 Rev. H • 6/24
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
