SimpliFire SF-INS30-BK Owner's Manual
Hide thumbs Also See for SF-INS30-BK:

Advertisement

Model(s):
SF-INS30-BK
• Important operating
a n d m a i n t e n a n c e
instructions included.
Congratulations!
Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood and gas burning
fireplaces. The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and
efficiency.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions
before using appliance.
INSTALLER: DO NOT DISCARD THIS MANUAL -
LEAVE FOR HOMEOWNER - SAVE THESE INSTRUCTIONS
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-INS30-BK and is the answer not in the manual?

Questions and answers

Summary of Contents for SimpliFire SF-INS30-BK

  • Page 1 Congratulations! Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood and gas burning fireplaces. The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency. READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN THIS PRODUCT.
  • Page 2: Important Instructions

    Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or the like. Arrange cord away from traffic areas and where it will not be tripped over. Do not tightly coil cord. SAVE THESE INSTRUCTIONS SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 3: Table Of Contents

    E. Contact Information ......16 SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 4: Warranty

    Fire fireplace within one year following the date of original purchase, that the SimpliFire fireplace will be free from defects in materials and workmanship at the time of manufacture. If a SimpliFire fireplace is found to be defective in materials or workmanship during the applicable warranty period, HHT will, at its option, repair or replace the SimpliFire fireplace.
  • Page 5: General Information

    We recommend that you record the following pertinent Homeowner Reference Information information about your fireplace. Model Name: ___________________________________________ Date purchased/installed: __________________ Serial Number: __________________________________________ Location on fireplace: _____________________ Dealership purchased from: _______________________________ Dealer Phone: __________________________ Notes: _______________________________________________________________________________________ _____________________________________________________________________________________________ SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 6: Getting Started

    Remote Control AAA Battery Front/Rear Leveling Bracket Screw ST4x8 B. Appliance Dimensions SHELL SIZE FRONT SIZE VIEWING AREA MODEL 11-7/8 20-1/2 29-7/8 22-7/8 33-1/8 21-7/8 18-1/8 SF-INS30-BK Figure 3.1 Appliance Dimensions SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 7: Location

    WITH PERMANENT MANTEL OR OTHER FINISHING MATERIALS. SURROUND AND APPLIANCE MUST BE REMOVABLE IN CASE FUTURE SERVICE IS REQUIRED. Figure 3.2 Mantel - Surround SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 8: Installation

    Depth Front Width Note: Minimum dimensions apply to both combustible and non-combustible construction. MINIMUM CHASE DIMENSION Location Inches Millimeters Rear Width Front Width Height 21-3/8 Depth 11-1/2 Figure 4.1 Clearance Requirements SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 9: Appliance Preparation

    Use two (2) screws (ST4 x 8) per bracket to secure the appliance. See Figure 4.2. PRE-DRILLED HOLES LEVELING BRACKETS Figure 4.2 Pre-drilled Hole Locations SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 10: Install Surround

    See Figure 4.4. 7/8 in. 31-1/8 in. 40 in. Lorem 7/8 in. SCREW (x4) 31-1/8 in. 44 in. Height Width Depth SF-S14027-BK 1016 SF-S14432-BK 1118 Figure 4.4 Surround Dimensions & Installation SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 11: Installing Appliance

    Note: If the power supply is located outside the fireplace Figure 4.4 Mantel - Surround or chase, the cord can be routed through the bottom cor- ner of the surround to a nearby outlet. SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 12: Operating Instructions

    By pressing the FLAME button, the unit will cycle through four flame brightness levels. NOTE: Two Red Indicator Lights will display when on HIGH heat. Indication Flame Button Heater Button Figure 5.1 Manual Switch and Indicator Light SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 13: Operating By Remote Control

    The Timer can be set from selected. If no timer beep to confirm command to .5 hour up to 9 hours in 1 hour is set, there will be no desired timer setting. increments. indicator. SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 14: Maintenance

    WARNING! Risk of Electrical Shock! Any other servic- ing needed must be performed by an authorized service technician. Do not attempt to service the unit yourself. SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 15: Service Parts List

    Heater Tray Assembly HEATER-INS30 Fan Included ROTISS-INS30 Rotisserie (Rod, Motor, & Screws) Flame Screen FLAME-INS30 LED Assembly Includes all LEDs LED-INS30 Receiver RECEIVER-ELECT HRDW-BI Hardware Bag (Includes 2 leveling legs w/fasteners) 12/18 SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18...
  • Page 16: Contact Information

    SimpliFire, a brand of Hearth & Home Technologies 7571 215 Street West, Lakeville, MN 55044 www.hearthnhome.com Please contact your SimpliFire dealer or customer / technical support (877-320-0730) with any questions or concerns. For the location of your nearest SimpliFire dealer, please visit www.hearthnhome.com.
