INSTALLATION

This product can be built into new construction. Reference
Sections 4.A - 4.D for specific information for your instal-
lation.
A. Selecting Appliance Location
D3
Adjust framing dimension
for interior sheathing.
MODEL
SF-INC36
ELECTRICAL SPECIFICATIONS:
MODEL
SF-INC36
Figure 4.1 Clearance Requirements
D2
W2
*See Note
W1 H1
in. 41-1/2 34-3/4
mm 1054 883
(V)
120VAC/
240VAC
SimpliFire • SF-INC36 Owner's - Installation Manual • 4200-900 Rev D • 8/23
Note: The appliance can have a maximum of 1" of flooring
brought up to front edge if mounted directly to sub flooring.
See Figure 4.3.
D1
H1*
D1 W2
8-3/4 59
222 1499
(W)
1500/3000
W1
D2 D3
41-5/8 30-5/16
1057 770
(A)
12.5
