SimpliFire SF-INC36 Service Manual

1. Introduction

NOTICE! DO NOT discard any hardware while
servicing.
Some hardware must be reused.
This manual will assist a qualified service technician in the
replacement of parts. Contact your dealer to arrange a
service call by a qualified service technician.

Table of Contents

Table of Contents
1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2. Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3. Replacement Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4. Remote Pairing Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5. Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6. Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 1.1
SERVICE MANUAL
Model: SF-INC36
- Instructions -
SimpliFire • SF-INC36 Service Manual • 4200-960 • 8/23
WARNING! Risk of Shock!
Disconnect power before disas-
sembly or servicing.
WARNING! Risk of Shock! Always turn off circuit break-
er and ensure the heating element on the heater is cool
before cleaning or servicing.
WARNING! Risk of Fire! To reduce risk of fire, do not
store or use gasoline or any other flammable vapors or
liquids in the vicinity of the appliance.
WARNING! Risk of Electrical Shock! Servicing outlined
in this document must be performed by an authorized ser-
vice representative.
WARNING: If the information in these
instructions is not followed exactly
it may result in personal injury and/or
property damage.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Gloves
Safety glasses
#2 and #3 Phillips screwdrivers
Needle-nose pliers
3/32 slotted head screwdriver/or equivalent
1/4 in. Nut Driver
1/8 in. Hex Key
1
