Allusion Platinum
Series:
Model(s):
SF-ALLP50-BK
SF-ALLP60-BK
SF-ALLP72-BK
• Important operating
a n d m a i n t e n a n c e
instructions included.
Congratulations!
Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fireplaces.
The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions
before using appliance.
SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Please contact your SimpliFire dealer with any questions or concerns.
For the location of your nearest SimpliFire dealer,
please visit www.hearthnhome.com.
Printed in China - Copyright 2019
NOTICE
• Leave this manual with
party responsible for use
and operation.
Owner's Manual
Installation and Operation
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SimpliFire SF-ALLP50-BK
Summary of Contents for SimpliFire SF-ALLP50-BK
- Page 1 Congratulations! Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fireplaces. The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency. READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN THIS PRODUCT.
-
Page 2: Important Instructions
Return appliance to authorized service facility for examination, electrical or mechanical adjustment or repair. • Do not use outdoors. SAVE THESE INSTRUCTIONS SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 3: Table Of Contents
D. Service Parts List ......17 E. Contact Information ......20 SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 4: Warranty
Fire fireplace within one year following the date of original purchase, that the SimpliFire fireplace will be free from defects in materials and workmanship at the time of manufacture. If a SimpliFire fireplace is found to be defective in materials or workmanship during the applicable warranty period, HHT will, at its option, repair or replace the SimpliFire fireplace. -
Page 5: General Information
We recommend that you record the following pertinent information about your fireplace. Model Name: ___________________________________________ Date purchased/installed: __________________ Serial Number: __________________________________________ Location on fireplace: _____________________ Dealership purchased from: _______________________________ Dealer Phone: __________________________ Notes: _______________________________________________________________________________________ SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 6: Getting Started
ST4X40 Screws (appliance to framing) Type NM-B Wire Strain Relief Small Crystal Stones 1 bag Large Crystal Stones 1 bag White Ceramic Stones 1 bag Glass Screw Vanity Cover Power Cord SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 7: Appliance Dimensions
1329 1219 1283 62-5/16 20-7/16 60-1/2 19-3/8 5-5/8 SF-ALLP60-BK 1583 1473 1537 74-5/16 20-7/16 72-1/2 19-3/8 5-5/8 SF-ALLP72-BK 1888 1778 1842 * Including Front Trim Figure 3.1 Appliance Dimensions SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 8: Location
4 in. min. 0 in. Outside Maximum Combustible and swing arc Wall Non-Combustible Mantel of adjacent Projections. min. 0 in. doors TRIM RING Floor Figure 3.2 Location and Clearances Requirements SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 9: Installation
5-3/4 to 6-1/2 in. Adjust framing dimensions for interior sheathing (wallboard sheathing). Model Model SF-ALLP50-BK SF-ALLP72-BK 1295 1854 SF-ALLP60-BK 1549 Figure 4.1 Framing and Wall Finishing for Recessed Installation SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 10: Appliance Preparation
(2) screws. See Figure 4.2. INTERIOR SCREWS (2) SIDE PANEL Figure 4.2 Interior Side Panels Covering Attachment Points for Recessed Mounting in 2 X 6 in. Framing SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 11: Electrical Connection / Installation
4. Replace terminal block cover plate and retaining screws. Wire Diagram Figure 4.10 Optional Power Cord Assembly (Only for Direct Wall Mount Installation) SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 12: Appliance Final Setup
Install Front Glass Panel 1. Angle the glass to place the bottom edge into the channel behind the outer trim. See Figure 4.12. Figure 4.12 Glass Front Installation SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 13: Operating Instructions
See Figure 5.1. Remote Heater Vent Indication Receiver Power Button Flame Button Heater Button Ember Bed Button Control Panel Flame Figure 5.1 Manual Operating Switches SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 14: Operating By Remote Control
Pressing the Light button changes the ember bed colors (14 color LIGHT No indicator. themes available - 13 colors and a colar rotating option), and turns it on/off. SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 15: Room Temperature And Thermostat Function
SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 16: Maintenance
WARNING! Risk of Electrical Shock! Any other servic- ing needed must be performed by an authorized service representative. Do not attempt to service the unit your- self. SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... -
Page 17: Service Parts List
Trim, 50” Remote REMOT-ELECT-ALL Main PCB PCB-ALLP Power Cord PLUGIN-ALLP LED Assembly, 50” (Ember and Flame Bed Included) LED-ALLP50 Button Assembly TOUCH-ALLP Screen and Flame Screen, 50” FLAME-ALLP50 8/19 SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19... - Page 18 Trim, 60” Remote REMOT-ELECT-ALL Main PCB PCB-ALLP Power Cord PLUGIN-ALLP LED Assembly, 60” (Ember and Flame Bed Included) LED-ALLP60 Button Assembly TOUCH-ALLP Screen and Flame Screen, 60” FLAME-ALLP60 8/19 SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19...
- Page 19 Trim, 72” TRIM-ALLP72 Remote REMOT-ELECT-ALL PCB-ALLP Main PCB Power Cord PLUGIN-ALLP LED Assembly, 72” (Ember and Flame Bed Included) LED-ALLP72 Button Assembly TOUCH-ALLP Screen and Flame Screen, 72” FLAME-ALLP72 8/19 SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19...
-
Page 20: Contact Information
Printed in China - Copyright 2019 SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK • 2044-980 Rev. C • 10/19...
