Seagull Models MESSERSCHMITT Bf 109E 60 Assembly Manual page 5

Turn the wing panel over and delect the
aileron in the opposite direction from the
opposite side. Apply thin C/A glue to each
hinge, making sure that the C/A penetrates
into both the aileron and wing panel.
Using C/A remover/debonder and a pa
per towel, remove any excess C/A glue that
may have accumulated on the wing or in the
aileron hinge area.
Repeat this process with the other wing
panel, securely hinging the aileron in place.
Ater both ailerons are securely hinged,
irmly grasp the wing panel and aileron to
make sure the hinges are securely glued and
cannot be pulled out. Do this by carefully ap-
plying medium pressure, trying to separate
the aileron from the wing panel. Use caution
not to crush the wing structure.
Note : Work the aileron up and down sev-
eral times to "work in" the hinges
and check for proper movement.
hin CA.
-
INSTALL THE AILERONS
CONTROL HORN.
Locate the aileron and lap control horns.
he taller control horn is used for the ailer-
ons, and the shorter horn for the laps.
Epoxy.
INSTALL FLAP CONTROL HORN.
Install the lap control horn using the
same method as same as the aileron con-
trol horns.
Fiberglass control horn
Epoxy.
Aileron control horn.
5
