Messerschmitt Bf 109E 60
THROTTLE SERVO ARM
INSTALLATION.
Install adjustable servo connector in the
servo arm as same as picture below:
Loctite secure.
INSTALLING THE RECEIVER SWITCH.
Install the switch into the precut hole in
the side, in the fuselage.
12
Adjustable servo
connector.
Servo arm.
hrottle servo arm.
3/32" Hole.
Trim and cut.
Instruction Manual.
INSTALLING THE ENGINE SWITCH.
Trim and cut.
Switch.
Switch.
