Module Programming - Directed DIRECTECHS DB3 Installation Manual

Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Ensure vehicle is in a safe location, and cannot move forward during programming. For vehicles
1
equipped with a manual transmission, make sure the gearshift lever is in the neutral position.
The harnesses must be connected in this exact order:
1. Connect the 14-pin.
2. Connect the 12-pin.
2
3. Connect the 10-pin.
4. Connect the 4-pin D2D cable (if being used).
When the LED turns ON solid red, proceed with the next step.
Press unlock on the OEM fob, then insert the key into the key switch and turn the ignition on.
3
The LED will flash green.
4
Wait for LED to turn solid green for 3 seconds, then off.
5
Turn the ignition off.
You have successfully completed the module programming sequence.
12
403.VW10 2.01 2013 Volkswagen Jetta
