Vehicle connections

The connection information listed below is specific to the 2013 Volkswagen Jetta. Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
9 403.VW10 2.01 2013 Volkswagen Jetta
©2023 Directed. All rights reserved.
Description
No Connection
No Connection
(DATA) HS CAN High
(DATA) HS CAN Low
(DATA) FT CAN High
(DATA) FT CAN Low
Relay N.O. (+) 12 Volt Input
Relay COM. (+) Parking Light Output
Relay N.C.
[3]
Relay N.C. Key Wrap
[3]
Relay COM. Key Wrap
[3]
Relay N.O. Key Wrap
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
No Connection
[5]
(-) Trunk Release Output
(-) W2W Only - Door / Trunk Output
(-) W2W Only - E-Brake Output
[2]
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
No Connection
No Connection
[5]
(MUX) Door Lock/Unlock Output
No Connection
No Connection
Connects To
Wire Location
No Connection
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 6
OBD-Data Link Connector, black 16 pin plug, pin 14
VESCM under driver dash, white 73 pin plug, pin 20
VESCM under driver dash, white 73 pin plug, pin 21
VESCM under driver dash, black 73 pin plug, pin 68
Headlight Switch, 17 pin plug, pins 14, 16
No Connection
Immobilizer Reader Coil on ignition switch, black 2 pin plug, pin 1
Refer to "Immobilizer interface with OEM immobilizer receiver" section for
instructions.
Immobilizer Reader Coil on ignition switch, black 2 pin plug, pin 1
Refer to "Immobilizer interface with OEM immobilizer receiver" section for
instructions.
Immobilizer Reader Coil on ignition switch, black 2 pin plug, pin 1
Refer to "Immobilizer interface with OEM immobilizer receiver" section for
instructions.
VESCM under driver dash, black 73 pin plug, pin 68
Connects To
Wire Location
No Connection
VESCM under driver dash, black 73 pin plug, pin 23
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
VESCM under driver dash, black 73 pin plug, pin 24
No Connection
No Connection
(+/-) Wire Color
Data Orange/Black
Data Orange/Brown
Data Orange/Green
Data Orange/Brown
+ Red/Yellow (30A)
+ Gray/Red (exterior);
Gray/Blue (interior/license)
RF Blue
RF Blue
RF Blue
+ Red/Yellow (30A)
(chassis ground)
(+/-) Wire Color
- Violet (rear handle switch)
- Blue/Red (driver door key lock)
