403.MA2

DB3

v4.12

2009 Mazda 3

Table of Contents

Summary of Contents for Directed DIRECTWIRE DIRECTECHS DB3

Page 1 403.MA2 v4.12 2009 Mazda 3...
Page 2: Table Of Contents
Contents Introduction Vehicle function compatibilities Pre-Installation and application warnings Installation Wiring diagram with OEM Alarm Wiring diagram without OEM Alarm Locating components in the vehicle Vehicle connections Module programming Method 2 (using 2 keys) Method 1 (using 1 key and Key2GO) - Recommended method Key2GO Connecting the module Important note for knob-style vehicles...
Page 3: Introduction
Introduction DB3 is an all-in-one door lock and override module. Warning! This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs Mobile application for smartphones. Refer to “Connecting the module” for more information. 403.MA2 4.12 2009 Mazda 3 ©2023 VOXX•DEI LLC.
Page 4: Vehicle Function Compatibilities
Vehicle function compatibilities This section lists all the functions compatible with this vehicle for the installation illustrated in this guide. Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart. Door Lock Control Entry Monitoring ALL Door Pins Door Unlock Entry Monitoring Hood Pin Key2GO...
Page 5: Pre-Installation And Application Warnings
Pre-installation and application warnings Firmware notes: This section highlights important information for this specific firmware and will assist in pricing accordingly, as well as bringing awareness to any operational or vehicle limitations. T-Harness Keys required for Keys required for compatible programming operation Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic...
Page 6: Installation
Wiring diagram with OEM Alarm Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( Ignition Connector XKD2D65 OBDII Diagnostic Connector MS CAN High: Pin 3 HS CAN High: Pin 6 Refer to the Vehicle connections for wire and connector details.
Page 7: Wiring Diagram Without Oem Alarm
Wiring diagram without OEM Alarm Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( OBDII Diagnostic Connector Ignition Connector XKD2D65 MS CAN High: Pin 3 HS CAN High: Pin 6 Refer to the Vehicle connections for wire and connector details.
Page 9: Vehicle Connections
Vehicle connections The connection information listed below is specific to the 2009 Mazda 3. Refer to “Pre-installation and application warnings” for a list of important notes. Data 14-pin blue connector (H1) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color H1/1 Light Green...
Page 10 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color H3/1 Green (-) W2W Only - Lock Input Remote Starter H3/2 Blue (-) W2W Only - Unlock Input Remote Starter H3/3 Red/White (-) W2W Only - Trunk Input Remote Starter H3/4 White/Violet No Connection...
Page 11 Additional remote start connections (Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.) Connects To Wire Wire Location (+/-) Wire Color 12 Volts ignition switch black/red (30A) Accessory ignition switch pink/yellow Factory Alarm Arm driver kick --or-- passenger dash fuse box, brown 32 pin plug (J-06),...
Page 12: Module Programming
Module programming Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes. Method 2 (using 2 keys) Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift lever is in the neutral position.
Page 13: Method 1 (Using 1 Key And Key2Go) - Recommended Method
Method 1 (using 1 key and Key2GO) - Recommended method Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift lever is in the neutral position.
Page 14: Key2Go
Any first-time user must re-register to gain access to Key2GO, and some additional information will be required to complete the registration process, such as your Directed account number and store name. Key2GO is compatible with XKLoader2 and the online web tool, as well as XKLoader3 and the Directechs Mobile application.
Page 15: Important Note For Knob-Style Vehicles
Important note for knob-style vehicles Before starting the programming sequence, remove the metal key by sliding it out from the OEM FOB. The removal of the knob cover is necessary. 1- With the start knob in the OFF position, remove the auxiliary key from the advanced key. 2- Remove the cover of the start knob by pulling it outward while pressing both buttons on each side of the knob.
Page 16: Led Diagnostics And Troubleshooting
LED diagnostics and troubleshooting This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation. Module Programming Description Troubleshooting Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If Module has no power.
Page 17 Active Ground When Running (Status) Description Troubleshooting Ground When Running (Status) command The module has initialized the remote start sequence. received. Flashes green Ignition ON command received. The module has received the Ignition ON command and is processing the remote start sequence. Flashes red &...
Page 18: Soft Reset
Soft reset A module reset will only erase the steps perfomed in “Module programming”. The firmware and settings flashed to the module will not be affected. D2D installation Connect the 10-pin, 12-pin & 14-pin harnesses to the module. Press and hold the programming button, then connect the 4-pin D2D harness.
Page 19: Feature Programming
Feature programming To enter feature programming routine: Turn the ignition ON, then OFF. 2. Within 5 seconds, press and hold the programming button until the LED turns ON orange (after 3 seconds). 3. Release the programming button. The LED will flash green once slowly to indicate the feature number is 1. After a short delay, the LED flashes red rapidly to indicate the current option of feature 1 (e.g.
Page 20: Feature And Option List
Feature and option list It is recommended to configure all the features and options listed below using the configuration tool found on the module flashing page at www.directechs.com. The web offers more options; however, manual configuration of the features is possible using the information on this page.
Page 21: Limited One Year Consumer Warranty
Limited 12 Months Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor.
Page 22: Quick Reference Guide
Factory remote. Press the Remote Start button on the transmitter.* • Aftermarket remote. • Directed SmartStart application via your smartphone. & The parking lights will flash once to indicate the Parking lights flash x1 Press Remote vehicle is now in Pit Stop Mode.
