Wiring diagram with T-Harness (THFOD2)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
BCM
(black plug 'G'
at dash fuse box)
1 2 3 4 5 6
8 9 10 11 12
7
13 14 15 16
18 19
17
(+) 12V: Red, pin 22
22
20 21
Fuse 15A
40 52
51
27 39
14 26
25
1 13
BCM
(Blue plug 'E'
at dash fuse box)
(+) Parking Lights (L): Violet/Green, pin 25
5 403.FORD12 2.07 2022 Ford Transit
©2023 Directed. All rights
Gateway Module
(Black connector Gateway Module
on OBDII connector)
86 87
85
87a
30
(-) Parking Light Output: Yellow/Red
(+) Parking Lights (R): White/Orange, pin 51
2 x
3A Diodes
Type 1
T-Harness THFOD2
(optional)
(-) Ground: Brown/Red
).
Type 2
4-pin
connectors
NOT USED
Hood Pin
White/Black N.C.
Remote Start Safety
Override Switch
You can connect to
either a XL202 RFTD
OR a SmartStart
module.
Refer to the
SmartStart/XL202
Installation Notes for
more information.
