Directed Directechs DB3 Installation Manual

Directed Directechs DB3 Installation Manual

For 2013 bmw x3 (f25) eu
Hide thumbs Also See for Directechs DB3:
Table of Contents

Advertisement

Quick Links

Download this manual
Functions compatible with the 2013 BMW X3 (F25) EU
Arm Factory Security
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Driver Door Pin
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
EU compatible (DB3/DS4)
Factory Alarm Trigger Monitoring
Fuel Door Release
Ignition Status
Parking lights via hazard control
Power Sunroof
Power Windows Rolldown
Power Windows Rollup
Tach / RPM Output
Trunk / Hatch Release
403.BMW03
v2.47.06
2013 BMW X3 (F25) EU

Advertisement

Table of Contents
loading

Related Manuals for Directed Directechs DB3

Summary of Contents for Directed Directechs DB3

  • Page 1 403.BMW03 v2.47.06 2013 BMW X3 (F25) EU Functions compatible with the 2013 BMW X3 (F25) EU Arm Factory Security EU compatible (DB3/DS4) Brake Status (foot brake) Factory Alarm Trigger Monitoring Control of aftermarket alarm with OEM remote Fuel Door Release Disarm Factory Security Ignition Status Door Lock Control...

  • Page 2: Table Of Contents

    Contents Introduction Pre-installation and application warnings Installation Wiring diagram for automatic transmission vehicles Wiring diagram for manual transmission vehicles Locating components in the vehicle Vehicle connections Module programming Connecting the module LED diagnostics and troubleshooting Soft reset Hard reset Feature programming Feature and option list Limited one year consumer warranty Quick Reference Guide (customer copy)

  • Page 3: Introduction

    This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs Mobile application for smartphones. Refer to “Connecting the module” for more information. 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 4: Pre-Installation And Application Warnings

    [2] Tach wire: Optional connection required on some remote starters, which do not support a tach signal in D2D. [3] Key wrap: Refer to the Immobilizer interface section of the guide for additional information. [4] Handbrake Status: Mandatory connection on automatic and manual transmission vehicles. 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 5: Installation

    (-) Ground (-) PTS 1: (-) PTS 2: Orange, Black/White, pin 8 pin 7 Car Access System (white 26-pin conn. under driver dash) (-) PTS 3: White/Blue, pin 6 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 6: Wiring Diagram For Manual Transmission Vehicles

    (-) Ground (-) PTS 1: (-) PTS 2: Orange, Black/White, pin 8 pin 7 Car Access System (white 26-pin conn. under driver dash) (-) PTS 3: White/Blue, pin 6 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 7: Locating Components In The Vehicle

    Locating components in the vehicle 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 8: Vehicle Connections

    Car Access System (CAS) under driver dash, 26 pin plug, pin 7 black/white H2/5 Violet/White Remote Starter (AC) Tach Output Optional connection required on some remote starters, which do not support a tach signal in D2D. 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.
  • Page 9 (Data) TX H4/2 Black (-) Ground H4/3 Green (Data) RX H4/4 (+) 12 Volt RF 2-pin white connector (H5) Module Conn./Pin Color Description H5/1 No Connection H5/2 No Connection 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.
  • Page 10 (chassis ground) Hood Pin [1] Car Access System under driver dash, 41 pin plug, pin 38 violet/green Tachometer [2] OBD-Data Link Connector, 16 pin plug, pin 9 black 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 11: Module Programming

    When the configuration is completed, the LED will turn ON solid green for 3 seconds, then turn OFF. Press the PTS one time (1x) to turn the ignition OFF. You have successfully completed the module programming sequence. 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 12: Connecting The Module

    (12-pin) (D2D) (10-pin) (14-pin) W2W installation If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin harness to the module. (12-pin) (10-pin) (14-pin) 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 13: Led Diagnostics And Troubleshooting

    External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.
  • Page 14 The smart key was not detected, which prevents the system from shutting down the vehicle. Flashes red x 3 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down. Flashes red x 4 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 15: Soft Reset

    Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the LED starts & to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Solid Release 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 16: Feature Programming

    To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface for 30 seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 17: Feature And Option List

    Module will perform windows roll up and close sunroof upon lock command. and Sunroof 1. Key Slot* Key Interface Type 2. Mechanical Key 3. F10 4. Disabled Vehicle Takeover 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 18: Limited One Year Consumer Warranty

    This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.

  • Page 19: Quick Reference Guide (Customer Copy)

    HVAC settings based on external factors such as engine temperature. When the adjustments are complete, turn off the vehicle starter, either by remote or footbrake. 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.
  • Page 20 Press & hold for 1 second to remote start. * Press & hold for 5 seconds to activate the trunk release (optional). * Icon and remote appearance may differ depending on the model purchased. Notes 403.BMW03 2.47.06 2013 BMW X3 (F25) EU ©2023 Directed. All rights reserved.
