Omcan 0920E-HC Instruction Manual page 40

Parts Breakdown
Model PT-CN-1829E-HC
Item No. Description
AL989 Cabinet for 59043
AL990 Top Rail for 59043
AL964 Control Panel for 59043
AL991 Right Door for 59043
AB536 Gasket for 59043
AA388 Axis Cover for 59043
AA955 Left/Right Spring Hinge for 59043
AA360 Bottom Left Hinge for 59043
AF070 Upper Right Hinge for 59043
AL992 Left Door for 59043
61468 Left Bottom Hinge for 59043
AB200 Upper Left Hinge for 59043
AL966 Stand Off Bracket for 59043
AL967 Fixer for Cutting Board for 59043
AL993 Cutting Board for 59043
AL969 Inner Drain Pan for 59043
AA124 Power Switch for 59043
AL929 Thermostat for 59043
AL970 Left Lid Hinge for 59043
AL971 Right Lid Hinge for 59043
59043
Position Item No. Description
1 AL994 Lid for 59043
2 AB475 Lid Hinge Axis for 59043
3 AL995 Lid for 59043
4 AL973 Evaporator for 59043
Left Support of Evaporator Cover for
5, 11 AL974
59043
Right Support of Evaporator Cover for
6 AL975
59043
Upper Support of Evaporator Cover for
7 AL976
59043
8 AL977 Evaporator Fan Motor Holder for 59043
9 AL932 Condenser Fan Motor for 59043
10 AA962 Blade of Evaporator Fan Motor for 59043
12 AA971 Evaporator Fan Motor Cover for 59043
13 AL978 Evaporator Cover for 59043
14 AL979 Air Guide Sheet for 59043
15 AL980 Pan Bracket-25 for 59043
16 AF090 K Strip-3 Holes for 59043
17 AL981 K Strip-4 Holes for 59043
18 26884 K Clip for 59043
19 AL982 Shelf for 59043
20 AL983 Castor Support for 59043
21 AL984 Left Compressor Unit Track for 59043
Position Item No.
22 AL985
23 AL986
24 AB527
25 AG448
26 AA764
27 AL996
28 AB595
29 AI968
30 AA874
31 AL987
32 AI372
33 AI373
34 26246
35 26247
36 AL988
37 AB169
38 AA133
39 AA135
40 AA379
41
40
Description Position
Right Compressor Unit Track for 59043 42
Compressor Unit Installation Board
43
for 59043
Condenser for 59043 44
Evaporator Fan Motor for 59043 45
Condenser/Evaporator Fan Motor Blade
46
for 59043
Condenser Fan Cover for 59043 47
Filter Fixer for 59043 48
Filter for 59043 49
Outer Drain Pan for 59043 50
Air Shield Board for 59043 51
Compressor for 59043 52
Compressor Starting Components for
53 - 56
59043
Caster with Brake for 59043 57
Caster without Brake for 59043 58
Back Grill for 59043 59
Foaming Hole Cover for 59043 60
Drain Hose for 59043 61
Power Cord for 59043 62
Temperature Probe for 59043 63
