Omcan 0920E-HC Instruction Manual page 30

Parts Breakdown
Model PT-CN-0920E-HC
Item No. Description
AO056 Cabinet for 59129
AP026 Right Door for 59129
AO058 Gasket for 59129
AA955 Left/Right Spring Hinge for 59129
AA388 Axis Cover for 59129
AA360 Bottom Left Hinge for 59129
AF070 Upper Right Hinge for 59129
AP027 Left Door for 59129
61468 Left Bottom Hinge for 59129
AB200 Upper Left Hinge for 59129
AO070 Top Board for 59129
AO071 Cutting Board for 59129
AB253 Fixer for Cutting Board for 59129
AO072 Back Cover for 59129
AO073 Lid for 59129
AB256 Dowel for 59129
AB257 Plastic Bolt for 59129
AB258 Nut for 59129
AB259 Split Pin for 59129
AP028 Evaporator Cover for 59129
59129
Position Item No. Description
1 AF100 Inner Drain Pan for 59129
2 AL945 Evaporator for 59129
3, 9 AL925 Right Clapboard of Evaporator for 59129
4 AL926 Left Clapboard of Evaporator for 59129
5 AL927 Evaporator Cover Support for 59129
6 AP029 Evaporator Fan Motor for 59129
7 AF080 Stand Off Bracket for 59129
8 AB320 Thermostat Installation Board for 59129
10 AL929 Thermostat for 59129
11 AP035 Pan Bracket Support for 59129
12 AL953 Pan Bracket-15 for 59129
13 AL954 Pan Bracket-25 for 59129
14 AO067 Castor Support for 59129
15 26247 Caster without Brake for 59129
16 26246 Caster with Brake for 59129
17 AO068 Assembling Panel Support for 59129
18 AL939 Left Compressor Unit Track for 59129
Compressor Unit Installation Board for
19 AF086
59129
20 AF085 Compressor Unit Track for 59129
21 AB159 Condenser for 59129
Position Item No.
22 AI321
23 AI391
24 AA207
25 AB595
26 AB594
27 AF087
28 AI372
29 AI373
30 AF089
31 AF090
32 26884
33 AN875
34 AL948
35 AP031
36 AB169
37 AA133
38 AA135
39 AA379
40 AA596
41 AL950
30
Description Position
Condenser Fan Motor for 59129 42
Blade of Condenser Fan Motor for 59129 43
Condenser Fan Motor Cover for 59129 44
Filter Fixer for 59129 45
Filter D25x160-B for 59129 46
Outer Drain Pan for 59129 47
Compressor for 59129 48
Compressor Starting Components for
49-52
59129
K Strip-2 Holes for 59129 53
K Strip-3 Holes for 59129 54
K Clip for 59129 55
Shelf for 59129 56
Thermostat Installation Board for 59129 57
Back Grill for 59129 58
Foaming Hole Cover for 59129 59
Drain Hose for 59129 60
Power Cord for 59129 61
Temperature Probe for 59129 62
Thermometer for 59129 63
Evaporator Fan Cover for 59129 64
