- Page 1 Refrigerated Sandwich Prep Units Models PT-CN-0686-HC, 1194-HC, 1524-HC, 1778-HC, 0711-HC, 1194-H, 1537-HC Items 50045, 50046, 50047, 50048, 50049, 50050, 50051 Instruction Manual Revised - 08/29/2019 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model PT-CN-0686-HC / Model PT-CN-1194-HC / Model PT-CN-1524-HC Model PT-CN-1778-HC / Model PT-CN-0711-HC / Model PT-CN-1194-H Model PT-CN-1537-HC Section Page General Information ----------------------------------------------------------------------------------------- 3 - 4 Safety and Warranty ---------------------------------------------------------------------------------------- 4 - 5 Technical Specifications ------------------------------------------------------------------------------------ 6 - 7... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 2 YEARS PARTS AND LABOUR / 5 YEARS PARTS ONLY ON COMPRESSOR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use.
-
Page 6: Technical Specifications
Technical Specifications REFRIGERATED PREP TABLES Model PT-CN-0686-HC PT-CN-1194-HC PT-CN-1524-HC PT-CN-1778-HC Temperature Range 0.5°C -5°C / 33°F - 41°F Max Ambient 32°C / 90°F Temperature Rating Horsepower 1/5 HP 1/4 HP 3/4 HP Electrical 110V / 60Hz / 1Ph Amps 2.9A 4.6A... -
Page 7: Installation
Technical Specifications MEGA REFRIGERATED PREP TABLES Model PT-CN-0711-HC PT-CN-1194-H PT-CN-1537-HC Temperature Range 0.5°C ~ 5°C / 33°F ~ 41°F Max Ambient Temperature 32°C / 90°F Rating Horsepower 1/5 HP 1/4 HP Electrical 110V / 60Hz / 1Ph Amps 2.9A 4.6A 4.8A Refrigerant R290... - Page 8 Installation • Install the unit in an indoor, well-ventilated area. - Unit performs more efficiently in a well-ventilated area. - For best performance, please maintain clearance of 6” on the back of the unit. - Outdoor use may cause decreased efficiency and damage to the unit. •...
-
Page 9: Maintenance
Installation freezing point, melting any accumulated frost. Run-off water is drained into the evaporator pan and evaporated. Freezer coils are defrosted electrically. Automatic defrost timers are built-in to the refrigeration system and may not be adjusted. The defrost timers automatically initiate at pre-set intervals and for a pre-determined duration. PLEASE NOTE: Excessive door opening should be avoided in order to maintain cabinet temperature and to eliminate the possibility of coil freeze-up. -
Page 10: Troubleshooting
Maintenance cover the fan motor to prevent moisture damage. CLEANING THE INTERIOR OF UNIT • When cleaning the cabinet interior, use a solvent of warm water and mild soap. • Do not use steel wool, caustic soap, abrasive cleaners, or bleach that may damage the stainless steel surface. - Page 11 Troubleshooting Condensing unit runs for long Excessive amount of warm product Allow adequate time for Product to periods of time. Placed in cabinet. cool down. Prolonged door opening or door Ensure doors are closed when not ajar. in use. Avoid opening doors for long periods of time.
-
Page 12: Controller Instructions
Controller Instructions Digital controller model: PJEZ for cooler Display and functions During normal operation, the controller displays the value of the probe set using parameter/4(=1 ambient probe, default, = 2 second probe, = 3 third probe).In addition, the display has LEDs that indicate the activation of the control functions (see Table 1), while the 3 buttons can be used to activate/deactivate some of the functions(see Table 2). - Page 13 Controller Instructions Table of Functions activated by the buttons - Models S, X, Y, C (Table 2) Button Normal Operation Start Up Pressing the Button Alone Pressed Together More than 3 sec: toggle ON/ Start/Stop ON/OFF continuous cycle Down More than 3 sec: start/stop Pressed For 1 sec.
- Page 14 To exit the menu without saving the changed values (exit by timeout) do not press any button for at least 60 s. REFERENCE Item Number Model Number Description Manufacturer Model Number Refrigerated Prep Table 27” / 686mm 50045 PT-CN-0686-HC SCL1-HC 110V/60/1 ETL cETLus Refrigerated Prep Table 47” / 1194mm 50046 PT-CN-1194-HC SCL2-HC 110V/60/1 ETL cETLus Refrigerated Prep Table 60”...
-
Page 15: Parts Breakdown
Parts Breakdown Model PT-CN-0686-HC 50045... - Page 16 Parts Breakdown Model PT-CN-0686-HC 50045 Item No. Description Position Item No. Description Position Item No. Description Position Blade of Condenser Fan Motor for AB248 Cabinet for SCL1-HC AA118 Evaporator for SCL1-HC AA208 SCL1-HC AB249 Door for SCL1-HC AB262 Fan Motor Installation Panel for SCL1-HC...
- Page 17 Parts Breakdown Model PT-CN-1194-HC 50046...
- Page 18 Parts Breakdown Model PT-CN-1194-HC 50046 Item No. Description Position Item No. Description Position Item No. Description Position AB307 Cabinet for SCL2-HC AB259 Split Pin for SCL2-HC AB213 Condenser for SCL2-HC AB308 Right Door for SCL2-HC AB314 Evaporator Cover for SCL2-HC AB049 Condenser Fan Motor for SCL2-HC Blade of Condenser Fan Motor for...
- Page 19 Parts Breakdown Model PT-CN-1524-HC 50047...
- Page 20 Parts Breakdown Model PT-CN-1524-HC 50047 Item No. Description Position Item No. Description Position Item No. Description Position AB361 Cabinet for SCL2-60-HC AB259 Split Pin for SCL2-60-HC AB213 Condenser for SCL2-60-HC AB362 Right Door for SCL2-60-HC AB369 Evaporator Cover for SCL2-60-HC AB049 Condenser Fan Motor for SCL2-60-HC Blade of Condenser Fan Motor for...
- Page 21 Parts Breakdown Model PT-CN-1778-HC 50048...
- Page 22 Parts Breakdown Model PT-CN-1778-HC 50048 Item No. Description Position Item No. Description Position Item No. Description Position AB433 Cabinet for SCL3-HC AB440 Evaporator Cover for SCL3-HC AB213 Condenser for SCL3-HC AB434 Right Door for SCL3-HC AB441 Inner Drain Pan for SCL3-HC AB049 Condenser Fan Motor for SCL3-HC Blade of Condenser Fan Motor for...
- Page 23 Parts Breakdown Model PT-CN-0711-HC 50049...
- Page 24 Parts Breakdown Model PT-CN-0711-HC 50049 Item No. Description Position Item No. Description Position Item No. Description Position Blade of Condenser Fan Motor for AB281 Cabinet for SCLM1-HC AA118 Evaporator for SCLM1-HC AA208 SCLM1-HC Fan Motor Installation Panel for AB282 Door for SCLM1-HC AB289 AA207 Condenser Fan Cover for SCLM1-HC...
- Page 25 Parts Breakdown Model PT-CN-1194-H 50050...
- Page 26 Parts Breakdown Model PT-CN-1194-H 50050 Item No. Description Position Item No. Description Position Item No. Description Position AB334 Cabinet for SCLM2-HC AB259 Split Pin for SCLM2-HC AB213 Condenser for SCLM2-HC AB335 Right Door for SCLM2-HC AB341 Evaporator Cover for SCLM2-HC AB049 Condenser Fan Motor for SCLM2-HC Blade of Condenser Fan Motor for...
- Page 27 Parts Breakdown Model PT-CN-1537-HC 50051...
- Page 28 Parts Breakdown Model PT-CN-1537-HC 50051 Item No. Description Position Item No. Description Position Item No. Description Position AB406 Cabinet for SCLM2-60-HC AB259 Split Pin for SCLM2-60-HC AB213 Condenser for SCLM2-60-HC AB407 Right Door for SCLM2-60-HC AB413 Evaporator Cover for SCLM2-60-HC AB049 Condenser Fan Motor for SCLM2-60-HC Blade of Condenser Fan Motor for...
-
Page 29: Electrical Schematics
Electrical Schematics Model PT-CN-0686-HC 50045... - Page 30 Electrical Schematics Model PT-CN-1194-HC 50046...
- Page 31 Electrical Schematics Model PT-CN-1524-HC 50047...
- Page 32 Electrical Schematics Model PT-CN-1778-HC 50048...
- Page 33 Electrical Schematics Model PT-CN-0711-HC 50049...
- Page 34 Electrical Schematics Model PT-CN-1194-H 50050...
- Page 35 Electrical Schematics Model PT-CN-1537-HC 50051...
-
Page 36: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... - Page 37 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 38 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
-
Page 39: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 40 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
