Omcan 0920E-HC Instruction Manual page 22

Parts Breakdown
Model PT-CN-1194E-HC
Item No. Description
AF092 Cabinet for 59046
AL940 Right Door for 59046
AB197 Gasket for 59046
AA955 Left/Right Spring Hinge for 59046
AA388 Axis Cover for 59046
AA360 Bottom Right Hinge for 59046
AF070 Upper Right Hinge for 59046
AL941 Left Door for 59046
61468 Left Bottom Hinge for 59046
AB200 Upper Left Hinge for 59046
AF095 Top Board for 59046
AF096 Cutting Board for 59046
AB253 Fixer for Cutting Board for 59046
AL942 Back Cover for 59046
AL943 Lid for 59046
AB256 Dowel for 59046
AB257 Plastic Bolt for 59046
AB258 Nut for 59046
AB259 Split Pin for 59046
AL944 Evaporator Cover for 59046
59046
Position Item No. Description
1 AF100 Inner Drain Pan for 59046
2 AL945 Evaporator for 59046
3, 9 AL925 Right Clapboard of Evaporator for 59046
4 AL926 Left Clapboard of Evaporator for 59046
5 AL927 Evaporator Cover Support for 59046
6 AL946 Evaporator Fan Motor for 59046
7 AF080 Stand Off Bracket for 59046
8 AB320 Thermostat Installation Board for 59046
10 AL929 Thermostat for 59046
11 AL947 Pan Bracket Support for 59046
12 AL930 Pan Bracket-15 for 59046
13 AL931 Pan Bracket-25 for 59046
14 AF104 Castor Support for 59046
15 26247 Caster without Brake for 59046
16 26246 Caster with Brake for 59046
17 AF105 Assembling Panel Support for 59046
18 AL939 Left Compressor Unit Track for 59046
Compressor Unit Installation Board for
19 AF106
59046
20 AF085 Compressor Unit Track for 59046
21 AB213 Condenser for 59046
Position Item No.
22 AL932
23 AI391
24 AL933
25 AB595
26 AI968
27 AA874
28 AI372
29 AI373
30 AF089
31 AF090
32 26884
33 AB220
34 AL948
35 AL949
36 AB169
37 AA133
38 AA135
39 AA379
40 AA596
41 AL950
22
Description Position
Condenser Fan Motor for 59046 42
Blade of Condenser Fan Motor for 59046 43
Condenser Fan Cover for 59046 44
Filter Fixer for 59046 45
Filter for 59046 46
Outer Drain Pan for 59046 47
Compressor for 59046 48
Compressor Starting Components for
49 - 52
59046
K Strip-2 Holes for 59046 53
K Strip-3 Holes for 59046 54
K Clip for 59046 55
Shelf for 59046 56
Thermostat Installation Board for 59046 57
Back Grill for 59046 58
Foaming Hole Cover for 59046 59
Drain Hose for 59046 60
Power Cord for 59046 61
Temperature Probe for 59046 62
Thermometer for 59046 63
Evaporator Fan Cover for 59046 64
