Parts Breakdown
Model PT-CN-1194E-HC
Item No. Description
AF092 Cabinet for 59050
AL940 Right Door for 59050
AB197 Gasket for 59050
AA955 Left/Right Spring Hinge for 59050
AA388 Axis Cover for 59050
AA360 Bottom Left Hinge for 59050
AF070 Upper Right Hinge for 59050
AL941 Left Door for 59050
61468 Left Bottom Hinge for 59050
AB200 Upper Left Hinge for 59050
AF142 Top Board for 59050
AF143 Cutting Board for 59050
AB253 Fixer for Cutting Board for 59050
AF144 Back Cover for 59050
AF145 Lid for 59050
AB256 Dowel for 59050
AB257 Plastic Bolt for 59050
AB258 Nut for 59050
AB259 Split Pin for 59050
AL944 Evaporator Cover for 59050
59050
Position Item No. Description
1 AF100 Inner Drain Pan for 59050
2 AL945 Evaporator for 59050
3, 9 AL925 Right Clapboard of Evaporator for 59050
4 AL926 Left Clapboard of Evaporator for 59050
5 AL927 Evaporator Cover Support for 59050
6 AP029 Evaporator Fan Motor for 59050
7 AF080 Stand Off Bracket for 59050
8 AB320 Thermostat Installation Board for 59050
10 AL929 Thermostat for 59050
11 AP036 Pan Bracket Support for 59050
12 AL953 Pan Bracket-15 for 59050
13 AL954 Pan Bracket-25 for 59050
14 AF104 Castor Support for 59050
15 26247 Caster without Brake for 59050
16 26246 Caster with Brake for 59050
17 AF105 Assembling Panel Support for 59050
18 AL939 Left Compressor Unit Track for 59050
Compressor Unit Installation Board for
19 AF106
59050
20 AF085 Compressor Unit Track for 59050
21 AB213 Condenser for 59050
Position Item No.
22 AI321
23 AI391
24 AA207
25 AB595
26 AB594
27 AA874
28 AI372
29 AI373
30 AF089
31 AF090
32 26884
33 AB220
34 AL948
35 AL949
36 AB169
37 AA133
38 AA135
39 AA379
40 AA596
41 AL950
32
Description Position
Condenser Fan Motor for 59050 42
Blade of Condenser Fan Motor for 59050 43
Condenser Fan Motor Cover for 59050 44
Filter Fixer for 59050 45
Filter D25x160-B for 59050 46
Outer Drain Pan for 59050 47
Compressor for 59050 48
Compressor Starting Components for
49-52
59050
K Strip-2 Holes for 59050 53
K Strip-3 Holes for 59050 54
K Clip for 59050 55
Shelf for 59050 56
Thermostat Installation Board for 59050 57
Back Grill for 59050 58
Foaming Hole Cover for 59050 59
Drain Hose for 59050 60
Power Cord for 59050 61
Temperature Probe for 59050 62
Thermometer for 59050 63
Evaporator Fan Cover for 59050 64
