Parts Breakdown
Model PT-CN-1270E-HC
Item No. Description
AL962 Cabinet for 59042
AL963 Top Rail for 59042
AL964 Control Panel for 59042
AL965 Door for 59042
AB500 Gasket for 59042
AA388 Axis Cover for 59042
AA955 Left/Right Spring Hinge for 59042
AA360 Bottom Left Hinge for 59042
AF070 Upper Right Hinge for 59042
AL966 Stand Off Bracket for 59042
AL967 Fixer for Cutting Board for 59042
AL968 Cutting Board for 59042
AL969 Inner Drain Pan for 59042
AA124 Power Switch for 59042
AL929 Thermostat for 59042
AL970 Left Lid Hinge for 59042
AL971 Right Lid Hinge for 59042
AL972 Lid for 59042
59042
Position Item No. Description
1 AB475 Lid Hinge Axis for 59042
2 AL973 Evaporator for 59042
Left Support of Evaporator Cover for
3 AL974
59042
Right Support of Evaporator Cover for
4 AL975
59042
Upper Support of Evaporator Cover for
5 AL976
59042
6 AL977 Evaporator Fan Motor Holder for 59042
7 AL932 Condenser Fan Motor for 59042
8 AA962 Blade of Evaporator Fan Motor for 59042
9 AA971 Evaporator Fan Motor Cover for 59042
10 AL978 Evaporator Cover for 59042
11 AL979 Air Guide Sheet for 59042
12 AL980 Pan Bracket-25 for 59042
13 AF090 K Strip-3 Holes for 59042
14 AL981 K Strip-4 Holes for 59042
15 26884 K Clip for 59042
16 AL982 Shelf for 59042
17 AL983 Castor Support for 59042
18 AL984 Left Compressor Unit Track for 59042
Position Item No.
19 AL985
20 AL986
21 AB159
22 AI960
23 AB595
24 AI968
25, 40 AA874
26, 41 AL987
27 AI386
28 AI392
29 26246
30 26247
31 AL988
32 AB169
33 AA133
34 AA135
35 AA379
36
38
Description Position
Right Compressor Unit Track for 59042 37
Compressor Unit Installation Board
38
for 59042
Condenser for 59042 39
Condenser Fan Cover for 59042 42
Filter Fixer for 59042 43
Filter for 59042 44
Outer Drain Pan for 59042 45
Air Shield Board for 59042 46
Compressor for 59042 47
Compressor Starting Components for
48 - 51
59042
Caster with Brake for 59042 52
Caster without Brake for 59042 53
Back Grill for 59042 54
Foaming Hole Cover for 59042 55
Drain Hose for 59042 56
Power Cord for 59042 57
Temperature Probe for 59042 58
