Parts Breakdown
Model PT-CN-0686E-HC
Item No. Description
AF068 Cabinet for 59045
AL920 Door for 59045
AB250 Gasket for 59045
AA955 Left/Right Spring Hinge for 59045
AA388 Axis Cover for 59045
AA360 Bottom Left Hinge for 59045
AF070 Upper Right Hinge for 59045
AF071 Top Board for 59045
AF072 Cutting Board for 59045
AB253 Fixer for Cutting Board for 59045
AL921 Back Cover for 59045
AL922 Lid for 59045
AB256 Dowel for 59045
AB257 Plastic Bolt for 59045
AB258 Nut for 59045
AB259 Split Pin for 59045
AL923 Evaporator Cover Support for 59045
AF076 Inner Drain Pan for 59045
AL924 Evaporator for 59045
59045
Position Item No. Description
1 AL925 Right Clapboard of Evaporator for 59045
2 AL926 Left Clapboard of Evaporator for 59045
3 AL927 Evaporator Cover Support for 59045
4 AL928 Evaporator Fan Motor for 59045
5 AF080 Stand Off Bracket for 59045
6 AB320 Thermostat Installation Board for 59045
7 AL929 Thermostat for 59045
8 AL930 Pan Bracket-15 for 59045
9 AL931 Pan Bracket-25 for 59045
10 AF083 Castor Support for 59045
11 26247 Caster without Brake for 59045
12 26246 Caster with Brake for 59045
13 AF084 Assembling Panel Support for 59045
14 AF085 Compressor Unit Track for 59045
Compressor Unit Installation Board for
15 AF086
59045
16 AB159 Condenser for 59045
17 AL932 Condenser Fan Motor for 59045
18 AI391 Blade of Condenser Fan Motor for 59045
19 AL933 Condenser Fan Cover for 59045
Position Item No.
20 AB595
21 AI968
22 AF087
23 AF088
24 AL934
25 AF089
26 AF090
27 26884
28 AK197
29 AL935
30 AB169
31 AA133
32 AA135
33 AA379
34 AA596
35 AL936
36 AL937
37 AL938
38 AL939
18
Description Position
Filter Fixer for 59045 39
Filter for 59045 40
Outer Drain Pan for 59045 41
Compressor for 59045 42
Compressor Starting Kit for 59045 43 - 46
K Strip-2 Holes for 59045 47
K Strip-3 Holes for 59045 48
K Clip for 59045 49
Middle Shelf for 59045 50
Thermostat Installation Board for 59045 51
Foaming Hole Cover for 59045 52
Drain Hose for 59045 53
Power Cord for 59045 54
Temperature Probe for 59045 55
Thermometer for 59045 56
Evaporator Fan Cover for 59045 57
Back Grill for 59045 58
Pan Bracket Support for 59045 59
Left Compressor Unit Track for 59045 60
