Omcan 0920E-HC Instruction Manual page 34

Parts Breakdown
Model PT-CN-1537E-HC
Item No. Description
AF108 Cabinet for 59051
AL955 Right Door for 59051
AB363 Gasket 720x635mm for 59051
AA955 Left/Right Spring Hinge for 59051
AA388 Axis Cover for 59051
AA360 Bottom Left Hinge for 59051
AF070 Upper Right Hinge for 59051
AL956 Left Door for 59051
61468 Left Bottom Hinge for 59051
AB200 Upper Left Hinge for 59051
AF147 Top Board for 59051
AF148 Cutting Board for 59051
AB253 Fixer for Cutting Board for 59051
AL957 Back Cover for 59051
AL958 Lid for 59051
AB256 Dowel for 59051
AB257 Plastic Bolt for 59051
AB258 Nut for 59051
AB259 Split Pin for 59051
AL959 Evaporator Cover for 59051
59051
Position Item No. Description
1 AF116 Inner Drain Pan for 59051
2 AI371 Evaporator for 59051
3, 9 AL925 Right Clapboard of Evaporator for 59051
4 AL926 Left Clapboard of Evaporator for 59051
5 AL927 Evaporator Cover Support for 59051
6 AL928 Evaporator Fan Motor for 59051
7 AF080 Stand Off Bracket for 59051
8 AB320 Thermostat Installation Board for 59051
10 AL929 Thermostat for 59051
11 AL960 Pan Bracket Support for 59051
12 AL953 Pan Bracket-15 for 59051
13 AL954 Pan Bracket-25 for 59051
14 AF120 Castor Support for 59051
15 26247 Caster without Brake for 59051
16 26246 Caster with Brake for 59051
17 AF121 Assembling Panel Support for 59051
18 AL939 Left Compressor Unit Track for 59051
Compressor Unit Installation Board for
19 AF106
59051
20 AF085 Compressor Unit Track for 59051
21 AB213 Condenser for 59051
Position Item No.
22 AL932
23 AI391
24 AL933
25 AB595
26 AI968
27 AA874
28 AI372
29 AI373
30 AF089
31 AF090
32 26884
33 AB388
34 AL948
35 AL961
36 AB169
37 AA133
38 AA135
39 AA379
40 AA596
41 AL936
34
Description Position
Condenser Fan Motor for 59051 42
Blade of Condenser Fan Motor for 59051 43
Condenser Fan Cover for 59051 44
Filter Fixer for 59051 45
Filter for 59051 46
Outer Drain Pan for 59051 47
Compressor for 59051 48
Compressor Starting Components for
49 - 52
59051
K Strip-2 Holes for 59051 53
K Strip-3 Holes for 59051 54
K Clip for 59051 55
Shelf for 59051 56
Thermostat Installation Board for 59051 57
Back Grill for 59051 58
Foaming Hole Cover for 59051 59
Drain Hose for 59051 60
Power Cord for 59051 61
Temperature Probe for 59051 62
Thermometer for 59051 63
Evaporator Fan Cover for 59051 64
