Omcan 0920E-HC Instruction Manual page 20

Parts Breakdown
Model PT-CN-0920E-HC
Item No. Description
AO056 Cabinet for 59034
AP026 Right Door for 59034
AO058 Gasket for 59034
AA955 Left/Right Spring Hinge for 59034
AA388 Axis Cover for 59034
AA360 Bottom Left Hinge for 59034
AF070 Upper Right Hinge for 59034
AP027 Left Door for 59034
61468 Left Bottom Hinge for 59034
AB200 Upper Left Hinge for 59034
AO060 Top Board for 59034
AO061 Cutting Board for 59034
AB253 Fixer for Cutting Board for 59034
AO062 Back Cover for 59034
AO063 Lid for 59034
AB256 Dowel for 59034
AB257 Plastic Bolt for 59034
AB258 Nut for 59034
AB259 Split Pin for 59034
AP028 Evaporator Cover for 59034
59034
Position Item No. Description
1 AF100 Inner Drain Pan for 59034
2 AL945 Evaporator for 59034
3, 9 AL925 Right Clapboard of Evaporator for 59034
4 AL926 Left Clapboard of Evaporator for 59034
5 AL927 Evaporator Cover Support for 59034
6 AP029 Evaporator Fan Motor for 59034
7 AF080 Stand Off Bracket for 59034
8 AB320 Thermostat Installation Board for 59034
10 AL929 Thermostat for 59034
11 AP030 Pan Bracket Support for 59034
12 AL930 Pan Bracket-15 for 59034
13 AL931 Pan Bracket-25 for 59034
14 AO067 Castor Support for 59034
15 26247 Caster without Brake for 59034
16 26246 Caster with Brake for 59034
17 AO068 Assembling Panel Support for 59034
18 AL939 Left Compressor Unit Track for 59034
Compressor Unit Installation Board for
19 AF086
59034
20 AF085 Compressor Unit Track for 59034
21 AB159 Condenser for 59034
Position Item No.
22 AI321
23 AI391
24 AA207
25 AB595
26 AB594
27 AF087
28 AI372
29 AI373
30 AF089
31 AF090
32 26884
33 AN875
34 AL948
35 AP031
36 AB169
37 AA133
38 AA135
39 AA379
40 AA596
41 AL950
20
Description Position
Condenser Fan Motor for 59034 42
Blade of Condenser Fan Motor for 59034 43
Condenser Fan Motor Cover for 59034 44
Filter Fixer for 59034 45
Filter D25x160-B for 59034 46
Outer Drain Pan for 59034 47
Compressor for 59034 48
Compressor Starting Components for
49 - 52
59034
K Strip-2 Holes for 59034 53
K Strip-3 Holes for 59034 54
K Clip for 59034 55
Shelf for 59034 56
Thermostat Installation Board for 59034 57
Back Grill for 59034 58
Foaming Hole Cover for 59034 59
Drain Hose for 59034 60
Power Cord for 59034 61
Temperature Probe for 59034 62
Thermometer for 59034 63
Evaporator Fan Cover for 59034 64
