Error
number
(value)
Process error
49
50
51
52
53
99
255
The error numbers displayed on operating units are different from those transmitted via
the field bus.
(1) An error has been assigned by the system which cannot be assigned. This situation can occur
with differences in the software versions between the power source and interface.
7.2.1

Interface for mechanised welding

No function of the external shut-down devices (emergency stop switch)!
If the emergency stop circuit has been realised using an external shut-down device via
the interface for mechanised welding, the device must be set for this setup. If this is not
observed, the power source will ignore the external shut-down devices and will not shut
down!
• Disconnect jumper 1 on PCB T320/1 (Tetrix) or M320/1 (Phoenix / alpha Q)!
099-000139-EW501
01.08.2011
Meaning
Ignition process error
Arc interruption error
Emergency stop/excess temperature
WF missing in MIG/MAG system or is not
correctly configured
In a system with the option for WF case
switching, an attempt has been made to
switch to a WF which does not exist
No connection to the welding power source
(e.g. system shut down)
(1)
Unknown error
Relevance
to system
Phoenix/Tetrix
Phoenix/Tetrix
Phoenix/Tetrix
Phoenix
Phoenix
Phoenix/Tetrix
Phoenix/Tetrix
NOTE
WARNING
Rectifying faults
Error messages (power source)
Error can be reset
Yes
Yes
No, resets itself
Yes
Yes
No, resets itself
Yes
