Item Symbol Description
1
digital
2
analog
3
4
5
6
7
8
9
10
11
12
13
14
15
099-000139-EW501
01.08.2011
Machine description – quick overview
Interfaces
Optional interface in the extension casing for assembly onto the power source
• RINTX11 robot interface
• BUSINTX10 industrial bus interface
19-pole mechanised welding interface (analogue)
(See chapter entitled "Design and function > interfaces".)
8-pole connection socket
Cooling unit control lead
19-pole connection socket (analogue)
Mechanised welding torch connection
7-pole connection socket (digital)
For connecting digital accessory components
G¼" connection thread, shielding gas connection, outlet
Connection socket, welding current -
Welding torch connection
Connection socket, welding current +
Workpiece connection
Key button, automatic cutout
Wire feed motor supply voltage fuse
press to reset a triggered fuse
G¼" connection thread, shielding gas connection, inlet
Cooling air outlet
Mains connection cable
Connection socket, 5-pole
Cooling unit voltage supply
Intermediate tube package strain relief
Machine feet
