PROFITEST H+E EASY CHECK
6

The Tester

6.1

Functions Description

The tester presents laypersons with the possibility of safely checking the functional-
ity of AC charging points without the need for the direct involvement of qualified
personnel.
Qualified personnel only need to be summoned for further action (e.g. repair) in the
event that a malfunction has actually been confirmed.
6.2

Device Characteristics

• The tester can only be used to test AC charging points in charging mode 3.
• Vehicle simulation (CP): the tester simulates the charging socket of the electric
vehicle. It can be connected to the charging socket or the type 2 plug of an AC
charging point.
• Cable simulation (PP): the tester checks values for 20 A cables with an auto-
matic program sequence.
If the 20 A test is not passed (e.g. if the AC charging point does not support
20 A cables), a test for 32 A cables can be started.
6.3

Scope of Delivery

Please check for completeness.
1 PROFITEST H+E EASY CHECK (M525F)
1 Charging cable (micro USB plug)
1 Operating instructions (this document)
7
