Advantech UNO-148 User Manual

Advantech UNO-148 User Manual

V2 industrial pc
Hide thumbs Also See for UNO-148:

Advertisement

Quick Links

Download this manual
User Manual
UNO-148 V2 Industrial
PC
Intel® Raptor Lake Processor
Automation Computer,
with 3 x LAN, 4 x COM, 2 x USB 3.2
Gen 2, 1 x USB 3.2 Gen 1,
1 x USB 2.0, 2 x DP 1.4, 8DI/8DO,
1 x mPCIe, 2 x M.2 M-Key,
1 x M.2 E-Key, 1 x Nano SIM Slot
and TPM 2.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the UNO-148 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech UNO-148

Summary of Contents for Advantech UNO-148

  • Page 1 User Manual UNO-148 V2 Industrial Intel® Raptor Lake Processor Automation Computer, with 3 x LAN, 4 x COM, 2 x USB 3.2 Gen 2, 1 x USB 3.2 Gen 1, 1 x USB 2.0, 2 x DP 1.4, 8DI/8DO, 1 x mPCIe, 2 x M.2 M-Key, 1 x M.2 E-Key, 1 x Nano SIM Slot...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.

  • Page 3: Product Warranty (2 Years)

    UNO148D33B2801-T UNO148D33B2802-T UNO148D33B2803-T Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.

  • Page 4: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.

  • Page 5: Safety Precautions - Static Electricity

    Discard used batteries according to the manufacturer’s instructions. In accordance with IEC 704-1:1982 specifications, the sound pressure level at the operator’s position should not exceed 70 dB (A). UNO-148 V2 User Manual...

  • Page 6: Consignes De Sécurité

    This equipment is not suitable for use in locations where children are likely to be present. If the equipment is used in a manner not specified by Advantech, the protection provided by the equipment may be impaired. The equipment contains no user-serviceable parts. Do not open. Return to the manufacturer for servicing.
  • Page 7 Jeter les piles usagées selon les instructions du fabricant. 安全指示 請仔細閱讀此安全操作說明。 請妥善保存此用戶手冊供日後參考。 用濕抹布清洗設備前，請確認拔除電源線。請勿使用液體或去污噴霧劑清洗設 備。 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。 請勿在潮濕環境中試用設備。 請在安裝前確保設備放置在可靠的平面上，意外摔落可能會導致設備損壞。 設備機殼的開孔適用於空氣對，從而防止設備過熱。請勿覆蓋開孔。 當您連接設備到電源插座前，請確認電源插座的電壓符合要求。 請將電源線佈置在人們不易絆倒的位置，請勿在電源線上覆蓋任何雜物。 請注意設備上所有的警告標示。 如果長時間不使用設備，請拔除與電源插座的連結，避免設備被超標的電壓波動 損壞。 請勿讓任何液體流入通風口，以免引起火灾或短路。 請勿自行打開設備。為了確保您的安全，請透過經認證的工程師來打開設備。 如遇下列情况，請由專業人員維修： 電源線或插頭損壞； 設備內部有液體流入； 設備曾暴露在過度潮濕環境中使用； 設備無法正常工作，或您無法透過用戶手冊來正常工作； 設備摔落或損壞； 設備有明顯外觀損； UNO-148 V2 User Manual...
  • Page 8 請勿將設備放置在超出建議溫度範圍的環境，即不要低於 -40°C （-40°F）或高 於 60 °C （140°F），否則可能會造成設備損壞。 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一 種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。 根據 IEC 704‐1:1982 規定，操作員所在位置音量不可高於 70 分貝。 限制區域：請勿將設備安裝於限制區域使用。 免責聲明：請安全訓示符合 IEC 704‐1 要求。研華公司對其內容之準確性不承 擔任何法律責任。 消费者若使用电源适配器供电，则应购买配套使用获得 CCC 认证并满足标准要 求的电源适配器。 UNO-148 V2 User Manual viii...

  • Page 9: Table Of Contents

    Certification ................... 4 Table 1.5: Certification..............4 1.4.6 Extension Kit (Optional) ..............5 Table 1.6: UNO-148-IS2EA Expansion unit (1 x iDoor and 1 x 2.5” SSD/HDD) ..............5 Table 1.7: UNO-148-P11EA Expansion unit (1 x PCIe x4 expan- sion)................5 Dimensions ....................
  • Page 10 AT/ATX Setting (SW8) ................49 Table A.12:AT/ATX Setting (SW8) ..........49 Riser Connector (CN12) ................. 50 Table A.13:Expansion Board to Board Connector Pin Assignments A.10 BIOS Operation..................51 A.10.1 Introduction ................. 51 Figure A.1 Main Setup Screen........... 51 UNO-148 V2 User Manual...
  • Page 11 Figure A.12S5 RTC Make Settings..........62 Figure A.13USB Configuration............ 63 Figure A.14Network Stack Configuration........64 Figure A.15Chipset ..............65 Figure A.16PCH-IO Configuration ..........66 Figure A.17Security ..............67 A.11 Storage RAID Configuration (VMD Setup)..........68 A.12 Dynamic Range Temperature Statement..........70 UNO-148 V2 User Manual...
  • Page 12 UNO-148 V2 User Manual...

  • Page 13: Chapter 1 Overview

    Chapter Overview This chapter outlines specifica- tions for UNO-148 V2.  Introduction  Safety Precautions  Accessories  Hardware Specifications  Dimensions...

  • Page 14: Introduction

    UNO-148 V2 is equipped with an 13th Generation Intel® Core™ i Processor (stan- dard 1.2 GHz, optional up to 4.9 Ghz) with 8 GB DDR5 RAM, and 3 x LAN, 4 x COM, 3 x USB 3.2 Gen 2, 1 x USB 2.0, 8 x DI, 8 x DO and 2 x DP 1.4.

  • Page 15: Packing List

    Packing List Please refer to the below packing list: UNO-148 V2 (with DIN-rail mount)  2 x 10-pin plug-in block for COM port  1 x 20-pin plug-in block for DIO  1 x 2-pin plug-in for Power  1 x earth-ground cable ...

  • Page 16: I/O Interfaces

    Operating, IEC 60068-2-64, 2 Grms, random, 5 ~ 500 Hz, 1hr/axis (SSD) Vibration Protection Operating, IEC 60068-2-64, 0.3 Grms, random, 5 ~ 500 Hz, 1hr/axis (HDD) 1.4.5 Certification Table 1.5: Certification Certification CE, FCC, CB, UL 61010-2-201, BSMI UNO-148 V2 User Manual...

  • Page 17: Extension Kit (Optional)

    1.4.6 Extension Kit (Optional) UNO-148 V2 features a modularized design. Advantech offers optional 2nd exten- sion kit. Table 1.6: UNO-148-IS2EA Expansion unit (1 x iDoor and 1 x 2.5” SSD/ HDD) Part number UNO-148-IS2EA 2nd stack extension kit to supports 1 x iDoor and 1 x 2.5”...

  • Page 18: Dimensions

    Dimensions 53 x 140 x 200 mm (W x D x H mm) Figure 1.1 UNO-148 V2 Dimensions UNO-148 V2 User Manual...
  • Page 19 88 x 140 x 200 mm (W x D x H mm) Figure 1.2 UNO-148 V2 Dimensions (With UNO-148-IS2EA Optional Extension Kit)) UNO-148 V2 User Manual...
  • Page 20 UNO-148 V2 User Manual...

  • Page 21: Chapter 2 Hardware Functionality

    Chapter Hardware Functionality This chapter details setup instruc- tions for the hardware functions of the UNO-148 V2. It includes connecting peripherals and indi- cators.  Introduction  External I/O Connectors  Internal I/O Connectors  LED Indicators  Reset Buttons...

  • Page 22: Introduction

    Introduction The following diagram shows the locations of the UNO-148 V2 motherboard’s key components and internal/external connectors. Figure 2.1 Diagram of Connector Locations on UNO-148 V2 (Top Side) Figure 2.2 Key Component Locations on UNO-148 V2 (Bottom Side) UNO-148 V2 User Manual...
  • Page 23 M.2 E-Key for 2230 Connector NVME1 M.2 M-Key for 2280 Connector NVME2 M.2 M-Key for 2280 Connector Internal DCOUT1 iDoor Power Connector CDI1 Reserved for iLink Connector CPUFAN1 CPU FAN Connector DIMM2 Memory Slot Connector DIMM1 Memory Slot Connector UNO-148 V2 User Manual...

  • Page 24: External I/O Connector

    Figure 2.4 Top View of UNO-148 V2 2.2.2 Power Connector UNO-148 V2 comes with a Phoenix connector that carries 10 - 36 V external power input, and features reversed wiring protection. Therefore, the system will not accrue damage from reversed polarity of ground lines and power lines.

  • Page 25: Lan: Ethernet Connectors

    2.2.4 USB Connectors UNO-148 V2 features 4 x USB ports that comply with USB EHCI (3 x USB 3.2, 1 x USB 2.0 (Type-A)) specifications. The USB connectors support plug-and-play and hot- swapping functionality for external devices. Additionally, this can be enabled/dis- abled in the BIOS menu.

  • Page 26: Com Connector

    2.2.6 COM Connector UNO-148 V2has 4 x COM RS232/422/485 ports of terminal block type. They offer transmission speeds of 50 ~115.2 kbps. The default mode for both COM ports (COM1&COM2) is RS-232 Mode. Settings can be adjusted via an on-board switch (SW1).

  • Page 27: Digital Inputs And Outputs

    And the below table indicates the mapping of DIO and Linux GPIO. Table 2.3: Digital Inputs and Outputs DI point Number DO point Number Use SW3 to set Wet Contact and Dry Contact for Digital input. UNO-148 V2 User Manual...
  • Page 28 Each of the 8 x isolated digital input channels accept voltages from 0 to 30 V. The fol- lowing figure shows how to connect an external input source to the isolated inputs of UNO- 148 V2. Figure 2.5 Isolated DI Wet Connection Diagram Figure 2.6 Isolated DI Dry Connection Diagram UNO-148 V2 User Manual...

  • Page 29: Internal I/O Connectors And Switches

    (500 mA max./ch), the board's current will sink from the external voltage source. The following figure shows how to connect an external output load to the isolated outputs on UNO-148 V2. Figure 2.7 Isolated DO Connection Diagram...
  • Page 30 Figure 2.8 Locations Internal I/O Connectors/Switches for UNO-148 V2 Table 2.4: Internal Connectors and Jumper Switches Label Function PCIE1 Riser connector MINIPCIE1 Mini PCIe connector COM34 Port RS232/422/485 settings COM12 Port RS232/422/485 settings DCOUT1 iDoor power connector DI Setting (Dry/Wet)

  • Page 31: Mpcie Connector

    Configure the UNO-148 V2 to match the needs of your application by setting switches. The following details the switch setting definitions: 2.3.1 mPCIe Connector There is one socket for a full-size Mini PCI Express card, labeled “MINI1” on the board. It supports the iDoor module for diversified applications such as isolated COM port, Profibus, WLAN GPRS, LTE, and MRAM.

  • Page 32: Led Indicators

    This product offers two antenna mounting holes pre-cut for users to install an antenna kit for LTE or wireless functions. Note! Please be aware of the Maximum OD value of the Antenna Hole when selecting the antenna. Figure 2.10 Diagram of Maximum OD Value for the Antenna Holes UNO-148 V2 User Manual...

  • Page 33: Chapter 3 Initial Setup

    Chapter Initial Setup This chapter explains how to Ini- tialize UNO-148 V2.  Chassis Grounding  Connecting Power  Storage Installation (Optional)  DIN-Rail Installation  Wireless Module Installation (Optional)  Expansion Module Installation (Optional)  Remote Power/On & Reset Set- ting ...

  • Page 34: Chassis Grounding

    Chassis Grounding UNO-148 V 2 provides good EMI protection and a stable grounding base. There is an easy-to-connect chassis grounding point. Figure 3.1 Chassis Grounding Connection The earth terminal should use a 16 AWG minimum size green and yellow conductor connector to connect to the earth.

  • Page 35: Connecting Power

    Take the following guidelines into consideration before wiring the device: The terminal block is suitable for 12-24 AWG (12 A). Torque value = 7 lb-in. Use copper conductors only. The temperature rating of the input connection cable should be higher than 95 °C (203°F). UNO-148 V2 User Manual...

  • Page 36: Storage Installation (Optional)

    Storage Installation (Optional) UNO-148 supports the installation of one M.2 2280 NVMe SSD. The installation is demonstrated in the following steps. 3.3.1 Installing M.2 2280 NVMe Remove the two screws from the UNO-148 V2 back cover. UNO-148 V2 User Manual...
  • Page 37 Attach the heatsink and NVME bracket using supplied screws. Paste the thermal pad onto heatsink. Remove screws (default locked on system). UNO-148 V2 User Manual...
  • Page 38 Install NVME and lock by post. Attach heatsink onto the system using three screws. UNO-148 V2 User Manual...

  • Page 39: 2230 Installation

    3.3.2 M.2 2230 Installation Remove screws (default locked on system), install M.2 2230 then re-attach with screws. UNO-148 V2 User Manual...

  • Page 40: Mpcie Installation

    3.3.3 mPCIE Installation Remove screws (default locked on system), install mPCIE installation, then re-attach with screws. UNO-148 V2 User Manual...

  • Page 41: Idoor Module

    3.3.4 iDoor Module Remove two screws from the bottom cover. Remove iDoor cover. UNO-148 V2 User Manual...
  • Page 42 Attach and tighten with five screws on 2nd stack to combine base unit. Attach the iDoor cover. UNO-148 V2 User Manual...

  • Page 43: Pcie Module

    Tighten screws back onto the bottom cover. 3.3.5 PCIE Module Remove the two screws from the bottom cover. UNO-148 V2 User Manual...
  • Page 44 Reattach the six screws on 2nd stack to combine the base unit. Attach the extension module on 2nd stack and remove the front cover and PCIE bracket. UNO-148 V2 User Manual...
  • Page 45 Install the PCIE card and secure it by tightening the screws. Attach the front and bottom cover then secure with screws. UNO-148 V2 User Manual...

  • Page 46: Idoor&Hdd Module

    3.3.6 iDoor&HDD Module Remove the two screws from the bottom cover. Remove iDoor cover and the HDD tray. UNO-148 V2 User Manual...
  • Page 47 Attach six screws on 2nd stack to combine the base unit. HDD extension slot: lock the HDD into the HDD tray and insert HDD tray on the track and tighten the screws. UNO-148 V2 User Manual...
  • Page 48 Tighten the two screws on the iDoor cover. Tighten the screws on the bottom cover. UNO-148 V2 User Manual...

  • Page 49: Din-Rail Installation

    Din-Rail Installation Hang up the din rail on one track and buckle it inwards to snap onto the other track. UNO-148 V2 User Manual...
  • Page 50 Pull down the “Release Latch” for disassembly using a screwdriver. Note! PCIe expansion module dimension limitations. The maximum length of the PcIe expansion module is 182 mm. UNO-148 V2 User Manual...

  • Page 51: Remote Power & Reset Settings

    Remote Power & Reset Settings UNO-148 V2 supports remote power & reset functions through a DI connector with the switch setting (SW8) on the motherboard. The default setting is for DI6/DI7 func- tionality. If you want to configure UNO-148 V2 for remote control functions, configure SW8 bit-2 to “on”, then DI6 can be used for remote power settings, and DI7 can be...
  • Page 52 UNO-148 V2 User Manual...

  • Page 53: Appendix A System Settings/Pin Assignments

    Appendix System Settings/Pin Assignments...

  • Page 54: Power Connector (Cn1)

    2500BASE-T: In MDI and in MDI-X configuration, MDI2- MDI[2]+/- corresponds to BI_DC+/- and MDI[3]+/- corresponds to BI_DD+/-. MDI3+ 100BASE-TX: Unused.  MDI3- 10BASE-T: Unused.  Table A.3: LEDs Left LED Right LED 100/10 Link 1000 Link 2500 Link Active Orange Green Green UNO-148 V2 User Manual...

  • Page 55: Usb Connectors (Cn5, Cn6)

    Table A.5: USB 3.0 Connector Pin Assignments Signal Name Description VBUS Power USB 2.0 differential pair Ground for power return StdA_SSRX- SuperSpeed receiver differential pair StdA_SSRX+ GND_DRIAN Ground for signal return StdA_SSTX- SuperSpeed transmitter differential pair StdA_SSTX+ UNO-148 V2 User Manual...

  • Page 56: Display Connector (Cn2, Cn3)

    Signal Name ML_Lane 0 (p) ML_Lane 0 (n) ML_Lane 1 (p) ML_Lane 1 (n) ML_Lane 2 (p) ML_Lane2 (2) ML_Lane 3 (p) ML_Lane 3 (n) CONFIG1 CONFIG2 AUX CH (p) AUX CH (n) Hot Plug Return UNO-148 V2 User Manual...

  • Page 57: Connector (Cn15)

    Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B WAKE_ON_WAN# M2_LTE_W2_DISABLE_N USB_Z_SSRX1- M2_SIM1_RESET USB_Z_SSRX1+ M2_SIM1_CLK M2_SIM1_DATA USB_C_SSTX1- M2_SIM1_PWR USB_C_SSTX1+ M2_SIM2_DET SATA1_RX+ SATA1_RX- SATA1_C_TX- SATA1_C_TX+ M2_SIM1_DET LTE_RST#_P67 +V3.3_M2 +V3.3_M2 +V3.3_M2 UNO-148 V2 User Manual...

  • Page 58: Mpcie Connector (Mini1)

    Connector (MINI1) Table A.8: mPCIe Connector Pin Assignments Signal Name Signal Name PCIE_WAKE#_3.3 +V3.3_MINI +V1.5 +V3.3 CLK_PCIE_mPCIe1- CLK_PCIE_mPCIe1+ WIFI_DISABLE# MINI_PLTRST# PCIE_mPCIe_RX4- +V3.3_MINI PCIE_mPCIe_RX4+ +V1.5 PCIE_TX2-_Z PCIE_TX2+Z USB_Z_P0- USB_Z_P0+ +V3.3_MINI +V3.3_MINI MPCIE_PWRSEL +V1.5 +V3.3_MINI UNO-148 V2 User Manual...

  • Page 59: Com Port Rs232/422/485 Settings

    This switch is used to select RS232/422/485 mode setting Default RS232 mode Bit 1 ON RS232 Mode Bit 2,3,4,5,6,7,8,9,10 OFF Bit 2,4,5 ON RS485 COM1 Mode Bit 1,3,6,7,8,9,10 OFF Bit 1,2,4,5 ON RS422 Mode Bit 3,6,7,8,9,10 OFF UNO-148 V2 User Manual...
  • Page 60 Bit 1,3,6,7,8,9,10 OFF Bit 1,2,4,5 ON RS422 Mode Bit 3,6,7,8,9,10 OFF Bit 6 ON RS232 Mode Bit 1,2,3,4,5,7,8,9,10 OFF Bit 7,9,10 ON RS485 COM4 Mode Bit 1,2,3,4,5,7,8 OFF Bit 6,7,9,10 ON RS422 Mode Bit 1,2,3,4,5,8 OFF UNO-148 V2 User Manual...

  • Page 61: Com Port Rs422/485 Termination Resistor Settings

    SW8 can be used for the AT/ATX setting. The default setting is AT mode. See the fol- lowing table for switch configuration. Table A.12: AT/ATX Setting (SW8) SW8 Default Description Instruction AT Mode (Default) Bit-1 off ATX Mode Bit-1 on UNO-148 V2 User Manual...

  • Page 62: Riser Connector (Cn12)

    Table A.13: Expansion Board to Board Connector Pin Assignments Signal Name Signal Name DCIN DCIN DCIN DCIN SMB_CLK SMB_DAT USB+ USB- PCIeX4_EN CLK+ CLK- RX0+ RX0- TX0+ TX0- SLP_S3 RX1+ RX1- TX1+ TX1- RX2+ RX2- TX2+ TX2- RX3+ RX3- TX3+ TX3- PLTRST SATA0_DET SATA1_DET UNO-148 V2 User Manual...

  • Page 63: Bios Operation

    AMI’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This information is stored in the NVRAM area so it retains the setup information when the power is turned off. UNO-148 V2 User Manual...
  • Page 64 Highlight System Time or System Date using the keys. Enter new val- ues through the keyboard, press the key or the keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. UNO-148 V2 User Manual...
  • Page 65 Advanced BIOS Setup option by highlighting it using the keys. All Advanced BIOS Setup options are described in this section. The Advanced BIOS Setup screens are shown below. The sub menus are described on the following pages. Figure A.3 Advanced BIOS Features Setup Screen UNO-148 V2 User Manual...
  • Page 66 SMM Use Delay Indication: Enable/Disable usage of SMM_DELAYED MSR for MP Sync in SMI. SMM Use Block Indication: Enable/Disable usage of SMM_BLOCKED MSR for MP Sync in SMI. SMM Use SMM en-US Indication: Enable/Disable usage of SMM_ENABLE MSR for MP Sync in SMI. UNO-148 V2 User Manual...
  • Page 67 A.10.2.4Power & Performance Figure A.5 Power & Performance Figure A.6 CPU - Power Management Control-1 UNO-148 V2 User Manual...
  • Page 68 Timed MWAIT  Enable/Disable Timed MWAIT Support Custom P-state Table  Add Custom P-state Table EC Turbo Control Mode  Enable/Disable EC Turbo Control mode Energy Performance Gain  Enable/Disable Energy Performance Gain CPU Lock Configuration  UNO-148 V2 User Manual...
  • Page 69 Maximum GT frequency limited by the user. Choose between 200MHz (RPN) AND 750MHz (RP0). Value beyond the range will be clipped to min/max sup- ported by SKU – Disable Turbo GT Frequency Enabled: Disables Turbo GT frequency. Disabled: GT frequency is not limited. UNO-148 V2 User Manual...
  • Page 70 A.10.2.6AMT Configuration Figure A.8 AMT Configuration Configure Intel Active Management Technology Parameters  UNO-148 V2 User Manual...
  • Page 71 Figure A.9 Secure Erase Mode Change Secure Erase module behavior  Simulated: Performs SE flow without erasing SSD. Real: Erase SSD. **If SATA device is used, OEM could use SECURE_ERASE_HOOK_PROTO- COL to remove SATA power to skip G3 cycle. UNO-148 V2 User Manual...
  • Page 72 A.10.2.8TPM Device Selection Figure A.10 TPM Device Selection Select TPM device: fTPM or dTPM. fTPM -Enables fTPM. dTPM-Disable fTPM  and Enable dTPM. Warnin: fTPM/dTPM will be disabled and all data saved on it will be lost. UNO-148 V2 User Manual...
  • Page 73 A.10.2.9NCT6126D Super IO Configuration: Serial Port 1 Configuration Figure A.11 NCT61260 Super IO Configuration Serial Port 1 Configuration  Set Parameters of Serial Port 1 (COM). UNO-148 V2 User Manual...
  • Page 74 Figure A.12 S5 RTC Make Settings Wake System from S5  Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. Select DynamicTime, System will wake on current time + Increase minute(s). UNO-148 V2 User Manual...
  • Page 75 Mass Storage Devices: USB  Mass storage device emulation type. “AUTO” enumerates devices according to their media format. Optical drives are emulated as “CDROM”, drives with no media will be emulated according to a drive type. UNO-148 V2 User Manual...
  • Page 76 A.10.2.12Network Stack Settings Figure A.14 Network Stack Configuration Network Stack  Enable/Disable UEFI Network Stack. UNO-148 V2 User Manual...
  • Page 77 Internal Graphics: Keep IGFX enabled based on the setup options. – VT-d – Above 4GB MMIO BIOS assignment: Enable/Disable above 4GB Memory- mapped IO BIOS assignment. This is enabled automatically when Aperture Size is set to 2048MB. UNO-148 V2 User Manual...
  • Page 78 Select “Disabled” for pin-based debug. If pin-based debug is enabled but USB overcurrent is not disabled, USB DbC does not work. Security Configuration  RTC Memory Lock: Enable will lock bytes 38h-3Fh in the lower/uppder 128-byte bank of RTC RAM UNO-148 V2 User Manual...
  • Page 79 Policy variables can be configured by a physically present user without full authentication. – Restore Factory Keys: Force System to User Mode. Install factory default Secure Boot key databases. – Key Management: Enables expert users to modify Secure Boot Policy vari- ables without full authentication UNO-148 V2 User Manual...
  • Page 80 Customers can enable RAID with 2 x SATA storage or 2 x NVMe storage. SATA RAID: M.2 B-Key & 2.5” HDD/SSD (UNO-148 base unit + UNO-148-IS2EA) PCIe RAID: M.2 M-Key & PCIe x4 slot (UNO-148 base unit + UNO-148-P11EA, needs PCIe x4 to M.2 M NVMe transfer card) Please refer to the below configuration instructions: Go to Chipset→VMD setup menu.
  • Page 81 Set VMD controller to “Enabled”. The system will detect the storage type (SATA/NVMe) and the RAID option will automatically pop up and the corresponding storage device will be installed. SATA RAID UNO-148 V2 User Manual...
  • Page 82 DTR is the range of temperature starting from boot (TBOOT) and transitioning to Cold-to-Hot (TBOOT + DTR) and/or Hot-to-Cold (TBOOT - DTR). A temperature out- side the DTR range requires a reboot but is not enforced by the hardware. (A manual reboot can recover the system). UNO-148 V2 User Manual...
  • Page 83 UNO-148 V2 User Manual...
  • Page 84 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2025...
