ADF Web AXIS HD67513-A1 User Manual

Can / ethernet - converter

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Industrial Electronic Devices

User Manual

Revision 2.002

English

CAN / Ethernet - Converter

(Order Code: HD67513-A1 – HD67513-B2)

for Website information:

www.adfweb.com?Product=HD67513

HD67513

for Price information:

www.adfweb.com?Price=HD67513-A1

www.adfweb.com?Price=HD67513-B2

Benefits and Main Features:

Mountable on Rail DIN

TCP/UDP protocols changeable with software

Easy to use software configuration

Industrial temperature range:

-40 °C / 85°C (-40°F / 185°F)

ADFweb.com Srl – IT31010 – Mareno – Treviso

Similiar

Products

Axis Solutions Pvt Ltd is the Authorized Distributor of

www.axisindia.in | info@axisindia.in

User Manual CAN / Ethernet - Converter

Document code: MN67513_ENG

Revision 2.002

HD67513-A1

For others Gateway / Adapter:

Ethernet to

Need help?

Do you have a question about the AXIS HD67513-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web AXIS HD67513-A1

Page 1 User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 1 of 17 Industrial Electronic Devices User Manual Revision 2.002 English CAN / Ethernet - Converter (Order Code: HD67513-A1 – HD67513-B2) for Website information: www.adfweb.com?Product=HD67513 HD67513 HD67513 HD67513-A1 HD67513-B2 for Price information:...
Page 2: Updated Documentation
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 2 of 17 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page Updated INDEX...
Page 3: Security Alert
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 3 of 17 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation.
Page 4: Connection Scheme
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 4 of 17 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme HD67513-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5 User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 5 of 17 Industrial Electronic Devices Figure 2: Connection scheme for HD67513-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6: Power Supply
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 6 of 17 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…19V AC and 8…35V DC. The consumption depends to the code of the device. For more details see the two tables below.
Page 7 User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 7 of 17 Industrial Electronic Devices CHARACTERISTICS: The Configurable CAN / Ethernet - Converter allows the following characteristics: TCP/UDP Ethernet protocols changeable with software; Mountable on Rail DIN; Temperature range -40°C to 85°C.
Page 8: New Project / Open Project
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 8 of 17 Industrial Electronic Devices NEW PROJECT / OPEN PROJECT: The “New Project” button creates the folder which contains the entire device configuration. A device configuration can also be imported or exported: To clone the configurations of a Programmable CAN to Ethernet Gateway in order to configure another device in the same manner, it is necessary to maintain the folder and all its contents;...
Page 9: Set Communication
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 9 of 17 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameter of two buses, CAN Bus and Ethernet. By pressing the “Set Communication” button from the main window for SW67513 (Fig. 3) the window “Set Communication”...
Page 10 User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 10 of 17 Industrial Electronic Devices RECEIVE COB: By pressing the “Receive COB” button from the main window for SW67513 (Fig. 3) the window “Receive CAN Frame” appears (Fig. 5). The means of the fields are: In the field “CobID”...
Page 11: Update Via Serial
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 11 of 17 Industrial Electronic Devices UPDATE VIA SERIAL Section “Update Via Serial” (Fig. 6): In order to load the parameters or update the firmware in the gateway, follow these instructions: Turn OFF the device;...
Page 12 User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 12 of 17 Industrial Electronic Devices CHARACTERISTICS OF THE CABLES: The connection with Ethernet socket must be with a Ethernet Cable with a RJ45 Plug. The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed).
Page 13: Ethernet Protocol
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 13 of 17 Industrial Electronic Devices ETHERNET PROTOCOL This protocol is able to read and write frames in the CAN net. Write Frames The transmission is very simple; it requires only what are the packets to send. In a single request it is possible to write at maximum 19 frames in the CAN net.
Page 14 User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 14 of 17 Industrial Electronic Devices Read Frames For reading Data it is necessary to have a map in the RAM memory that contains the Data that passing in the bus. This map is implemented in the “Compositor SW67513”...
Page 15: Mechanical Dimensions
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 15 of 17 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67513-A1 Figure 9: Mechanical dimensions scheme for HD67513-B2 ORDER CODE: Order Code: HD67513-A1 - CAN / Ethernet - Converter Order Code: HD67513-B2 - CAN / Ethernet - Converter (different enclosure)
Page 16: Other Regulations And Standards
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 16 of 17 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 17: Warranties And Technical Support
User Manual CAN / Ethernet - Converter Document code: MN67513_ENG Revision 2.002 Page 17 of 17 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...

This manual is also suitable for:

Axis hd67513-b2
