Appendix
Parameter overview – setting ranges
7.2.2

TIG welding

Name
Gas pre-flow time "t1"
Ignition current "t2" (percentage of main current "t4")
Start time "t2"
Slope time "t3"
Main current "t4" (depending on power source)
Pulse current "t4"
Pulse time "t4"
Spot time "t4"
Secondary current"t5" (percentage of main current)
Pulse pause current "t5"
Pulse pause time "t5"
Slope time "t6" (time from main current to end current )
End current "t7" (percentage of main current)
End current time "t7"
Gas post-flow time "t8"
7.2.3

MMA welding

Name
Main current AMP, depending on power source
Hot start current, percentage of AMP
Hot start current, absolute, depending on power source
Hot start time
Arcforce
92
Display Setting range
0,2 s 0
20 % 1
0,5 s 0,0
0,3 s 0,0
A
140 % 1
0,01 s 0,00 -
0,1 s 0,01 -
40 % 1
0,3 s 0,01
0,3 s 0,00 -
0,3 s 0,00 -
70 % 1
0,5 s 0,01 -
0,5 s 0,0
Display Setting range
- A -
120 % 1
- A -
0,5 s 0,0
0 -40
099-00HPXQ-EW501
- 20
- 200
- 20,0
- 20,0
-
200
20,0
20,0
200
20,0
20,0
20,0
- 200
20,0
- 20,0
- -
- 200
- -
- 10,0
- 40
