Functional characteristics
Special parameters (advanced settings)

5.10.1.14 Block JOB mode (P16)

The following accessory components support block JOB mode:
• Up/Down welding torch with one-digit 7-segment display (two keys)
Program 0 is always active in JOB 0 and program 1 in all other JOBs
In this operating mode, up to 30 JOBs (welding tasks) divided into three blocks can be called up with ac-
cessory components.
The following configurations must be carried out to use the block JOB operation:
• Set the "Program or Up/Down function" changeover switch to "Program"
• Set the JOB list to actual JOB list (special parameter P12 = "1")
• Enable block JOB mode (special parameter P16 = "1")
• Switch to block JOB mode by selecting one of the special JOBs 129, 130 or 131.
Simultaneous operation with interfaces such as RINT X11, BUSINT X11, DVINT X11 or digital
accessory components like the R40 remote control is not possible!
Allocation of JOB numbers to the display on the accessory components
JOB no.
Special JOB 1
Special JOB 2
Special JOB 3
JOB 0:
This JOB allows the manual setting of the welding parameters.
The selection of JOB 0 can be prevented by using the key switch or with the parameter "Block program 0"
(P2).
Key switch position
Key switch position
JOBs 1-9:
In each special JOB, nine JOBs (see Table) can be called up.
Nominal values for wire feed speed, arc correction, dynamics, etc. must be stored in advance in these
JOBs. This is done conveniently using the software PC300.Net.
If the software is not available, the "Copy to" function can be used to create user-defined JOB lists in the
special JOB areas (see explanations in the Chapter "JOB list switching (P12)").

5.10.1.15 Selecting programs with the standard torch trigger (P17)

Allows you to select a program or switch a program before starting welding.
You switch to the next program by tapping the torch trigger. Once the last enabled program is reached,
you start again at the beginning.
• Program 0 is the first enabled program, provided that it is not blocked.
(see also special parameter P2).
• The last enabled program is P15.
- If the programs are not limited by special parameter P4 (see special parameter P4).
- Or if the programs are limited for the selected JOB by the n cycle setting (see parameter P8).
• Welding starts when the torch trigger is held for longer than 0.64 s.
You can select programs with the standard torch trigger in all operating modes (non-latched, special non-
latched. latched and special latched).

5.10.1.16 Mean value display for superPuls (P19)

Function active (P19 = 1)
For superPuls, the performance mean value from program A (P
•
display (ex factory).
Function inactive (P19 = 0)
• Only the performance of program A is displayed for superPuls.
If the function is enabled and only "000" is shown on the machine display, this is a rare case of an
incompatible system set-up. Solution: Disable special parameter P19.
72
Display/selection on the accessory component
0 1 2
129 141 142
130 151 152
131 161 162
or special parameter P2 = 0: JOB 0 blocked.
or special parameter P2 = 1: JOB 0 can be selected.
3 4 5
143 144 145
153 154 155
163 164 165
) and program B (P
A
6 7 8
146 147 148
156 157 158
166 167 168
) is shown on the
B
099-00HPXQ-EW501
07.05.2021
9
149
159
169
