4 Machine control – Operating elements
4.1

Overview of control sections

For description purposes, the machine control has been divided into three sections (A, B, C) to
ensure maximum clarity. The setting range for the parameter values are summarised in the
parameter overview section > see 7.2 chapter.
Item Symbol
1
2
3
099-00HPXQ-EW501
07.05.2021
Machine control – Operating elements
Description 0
Control section A
> see 4.1.1 chapter
Control section B
> see 4.1.2 chapter
Control section C
> see 4.1.3 chapter
Figure 4-1
Overview of control sections
15
