4. Run the
recommended signal strength is two or three bars. If the signal
strength is low (a single bar), we do not guarantee stable
operation of the device. Consider relocating the device, as
repositioning even by 20 cm can signiDcantly improve the signal
strength. If there is still poor or unstable signal after the
relocation, use
5. Run
can be reduced and increased to simulate different conditions
at the installation location. If the installation spot is chosen
correctly, the keypad will have a stable signal strength of 2–3
bars.
6. If the tests are passed successfully, remove the keypad from
SmartBracket.
7. Fix the SmartBracket panel on the surface with bundled screws.
Use all Dxing points.
8. Place the keypad on the SmartBracket mounting panel.
9. Tighten the holding screw on the bottom of the keypad's
enclosure. The screw is needed for more reliable fastening and
protection of the keypad from quick dismantling.
https://support.ajax.systems/en/manuals/keypad-touchscreen/
If the LED indicator doesn't light up during placing on SmartBracket,
check the tamper status in the Ajax app, the integrity of the
fastening, and the tightness of the keypad Dxation on the panel.
Jeweller and
ReX 2
Signal Attenuation Test
When using other fasteners, ensure they do not damage or deform
the panel.
Wings signal strength tests. The
radio signal range extender.
. During the test, the signal strength
