KeyPad TouchScreen User manual | Ajax Systems Support
the wall.
8. Built-in buzzer.
9.
Tamper button
10. QR code with the device ID. It is used to add the keypad to the
Ajax system.
11. Power button.
12. Terminals for connecting a third-party power supply unit. They
can be removed from the holders when necessary.
13. Cable channel for routing the cable from the third-party power
supply unit.
14. Perforated part of the mounting panel to output cables from the
bottom.
15. The hole for attaching the SmartBracket mounting panel with a
holding screw.
Compatible hubs and range extenders
A compatible Ajax hub with the Drmware
higher is required for the keypad to operate.
Hub 2 (2G)
Hub 2 (4G)
https://support.ajax.systems/en/manuals/keypad-touchscreen/
.
Hubs
OS Malevich 2.16.1
Radio signal range extenders
ReX 2
14.08.2023, 17:03
and
Page 3 of 83
