When a KeyPad TouchScreen malfunction is detected, the Ajax app
displays a malfunction counter on the device icon. All malfunctions
are shown in the keypad states. Fields with malfunctions will be
highlighted in red.
A malfunction is displayed if:
The keypad enclosure is open (tamper is triggered).
No connection with the hub or radio signal range extender via
Jeweller.
No connection with the hub or radio signal range extender via
Wings.
The keypad battery is low.
The keypad temperature is outside acceptable limits.
Icons
