entered.
Error when adding a
card/key fob.
Successfully added
card/key fob.
Low battery.
Tamper triggering.
Jeweller/Wings Signal
Strength Test.
Firmware update.
https://support.ajax.systems/en/manuals/keypad-touchscreen/
The built-in buzzer emits
a short beep (if adjusted).
An appropriate
notiDcation is shown on
the display.
The LED indicator lights
up red once.
The built-in buzzer emits
a long beep.
An appropriate
notiDcation is shown on
the display.
The built-in buzzer emits
a short beep.
The LED indicator
smoothly lights up and
goes out when the
tamper is triggered, an
alarm is activated, or the
system is armed or
disarmed (if the
indication is activated).
The LED indicator lights
up red for 1 second.
The LED indicator lights
up green during the test.
The LED indicator
periodically lights up
green while the Drmware
is updating.
conDgured buttons'
volume.
The beep loudness
depends on the
conDgured buttons'
volume.
The beep loudness
depends on the
conDgured buttons'
volume.
Turns on after launching
an appropriate test in the
keypad settings
.
Turns on after launching
the Drmware update in
States
the keypad .
