3.
Enter Conveyor Tracking Setting
A.
Click the pencil icon the start node in the sub-thread to proceed with Conveyor Tracking Setting.
B.
For details, refer to 4.1.
4.
Select Tool for your conveyor tracking project.
Default options are "NOTOOL" and "HandCamera".
To ensure consistent precision, it is strongly recommended to use TM Calibration Set while teaching
the two CV points.
5.
Click the pencil icon of the CVSensor node.
Omron TM Collaborative Robot: Conveyor Tracking User's Manual
Figure 18: Start the project
Figure 19: Conveyor Tracking Setting
31
