DPS Telecom NetGuardian 420 DNP3 Hardware User Manual page 113

9 DX 1 Control 6
10 DX 1 Control 7
11 DX 1 Control 8
12 DX 2 Control 1
13 DX 2 Control 2
14 DX 2 Control 3
15 DX 2 Control 4
16 DX 2 Control 5
17 DX 2 Control 6
18 DX 2 Control 7
19 DX 2 Control 8
20 DX 3 Control 1
21 DX 3 Control 2
22 DX 3 Control 3
23 DX 3 Control 4
24 DX 3 Control 5
25 DX 3 Control 6
26 DX 3 Control 7
27 DX 3 Control 8
Analog Inputs
The following table lists Analog Inputs (Object 30). It is important to note that Analog Inputs, Analog
Output Control Blocks, and Analog Output Statuses are transmitted through DNP as signed numbers.
Note: Points 16-31 are used for DX 2 and DX 3 on units that DO NOT support D-Wire. For units that do
support D-Wire, only 1 DX is supported (points 8-15), and points 16-31 are reserved for D-Wire.
Analog Inputs
Static Variation: Obj 30 Var 03 - 32-Bit analog w/o flag
Request function codes supported: 1 (read)
Point ID
0
1
2
3
4
5
Description
Analog Channel 1
Analog Channel 2
Analog Channel 3
Analog Channel 4
Analog Channel 5
Analog Channel 6
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Default Unit
Voltage (VDC)
Voltage (VDC)
Voltage (VDC)
Voltage (VDC)
Voltage (VDC)
Voltage (VDC)
Class
0
0
0
0
0
0
107
