SEAGU LL 4 0
LOW WING TRAINER.
Cut.
8) Make a 90-degree bend at the mark
and cut off the excess wire leaving 10mm past
the bend.
9) Connect the linkage as shown and
secure the control wire with a wire keeper.
Repeat the procedure for the other
aileron servo.

INSTALLING THE MAIN GEAR WIRES.

6
3x10mm.
1) Using a modeling knife, remove the
covering from over the two main gear mount-
ing slots located in the bottom of the wing.
2) Insert the 90º bend of one main gear
wire into the predrilled hole in one mounting
slot.
7mm.
3) The landing gear wire is held in place
using two nylon landing gear straps and four
3mm x 10mm wood screws.
The straps should be located equal dis-
tance from the inside and outside ends
of the wire.
4) Using the two landing gear straps as
a guide, mark the locations of the four 3 x
10mm mounting screws onto the wing sur-
face.
Instruction Manual.
Gear mounting slot.
Landing gear wire.
