Network topology and access point hardware configuration
The network topology and access point hardware configuration can be configured using
the Mobility System Software. Please refer to the 3Com Corporation Mobility System
Software Configuration Quick Start Guide or the 3Com Wireless Switch and Controller
Installation and Basic Configuration Guide for more information.
Some useful commands are:
To create VLAN "v1" and add port 3 as a member of "v1":
set vlan 2 name v1 port 3
# 2 is the VLAN ID - must be unique for every VLAN on the
switch
To create a configuration for a model 3750 access point that is directly attached to port 1
of a Wireless Switch:
set port type ap 1 model ap3750 poe enable
Radio configuration
During VIEW Certification, APs were tested directly connected to a port on the
Wireless Switch (e.g. port 1), then the following commands will configure a specific
access point's radio to support the voice service:
set ap 1 radio 1 mode disable
# if the radio is currently enabled. Radio 1 is the 802.11b/g
radio
set ap 1 radio 1 radio-profile voice mode enable
# maps radio to the radio-profile and enables it
APs that are not directly connected to a port on the Wireless Switch, which 3Com calls a
distributed access point (DAP), were not tested. If they are desired, the radio is
configured with this command:
set dap 1 radio 1 mode disable
# if the radio is currently enabled. Radio 1 is the 802.11b/g
radio
set dap 1 radio 1 radio-profile voice mode enable
# maps radio to the radio-profile and enables it
