SpectraLink NetLink e340 Supplementary Manual page 4

Access Point Setup and Configuration
Installing software
3Com Mobility System firmware cannot be downloaded from the SpectraLink Web site;
therefore, you must use the software that was shipped with your product, or contact
3Com for the latest software release.
Command, comment, and screen text key
In the sections below you will find commands, comments, prompts, system responses,
or other screen-displayed information involved in the configuration process. This key
explains the text styles and symbols used to denote them.
Text Style
xxxxxxxx
<xxxxxxxx>
# xxxxxxxx
xxxxxxxx
Configuring the Mobility Exchange Switch
1. Using a standard RS-232 cable, connect the Wireless Switch to the serial port of a
terminal or PC.
2. Run a terminal emulation program (such as HyperTerminal) or use a VT-100
terminal with the following configuration:
Bits per second:
Data bits:
Parity:
Stop bits:
Flow control:
3. Press Enter three times to display the Wireless Switch login screen, and to get past
the username:
and passwords.
4. Type
enable
Service profile commands (SSID and security policy setup)
WPA2-PSK
Assume you are creating service profile "vowlan-wpa2" to define the ESSID "phones",
as well as a WPA2-PSK security policy. The following commands are needed to set up
the service for AP3750s:
set service-profile vowlan-wpa2 ssid-name phones
set service-profile vowlan-wpa2 wpa-ie disable
set service-profile vowlan-wpa2 rsn-ie enable
PN: 72-9966-00-D.doc
Denotes:
Typed command
Encryption key, domain name or other information specific to
your system that needs to be entered
Comment about a command or set of commands
Prompt, system response or other displayed information
9600
8
None
1
None
prompt and the password:
to enter privileged mode. There is no default password.
prompt. There are no default usernames
Page 4
