Replacing a Disk Drive in Gold RXT Media

Use this process to replace a 2.5-inch disk drive in Silver and Green RXT media.
1. Remove the two screws on the side panel of the RXT media (Figure 3-19).
Figure 3-19
The two side panel screws.
2. Slide the side panel out.
3. Locate the failed disk drive, which is labeled with the serial number you wrote
down from the Get RXT Media Pack Drive Status Diagnostic screen (Figure 3-2 on
page 24).
4. Pull the disk drive out by its tab (Figure 3-20).
5. Replace the failed disk drive with the new disk drive.
Chapter 3. Troubleshooting RXT Media
Figure 3-20
Pulling out the failed disk drive.
